纯CSS实现的荡秋千的女孩

奶油小泡芙
210 阅读4分钟

“我正在参加 码上掘金体验活动，详情：show出你的创意代码块”

一起养成写作习惯！这是我参与「掘金日新计划 · 4 月更文挑战」的第16天，点击查看活动详情。

前言

秋千一种运动和游戏的用具，在木架或铁架之间系上绳索，下面拴一块长板。人在板上用力蹬以来回摆动。

实现

布局

<div class="wrapper">
  <div class="swing">
	  <!-- 荡的部分 -->
    <div class="human">
		<!-- 上半部分 -->
      <div class="top-part">
        <div class="head">
			<!-- 头 -->
          <div class="hair"></div>
		  <!-- 头发 -->
          <div class="fringe"></div>
		  <!-- 刘海 -->
          <div class="eye"></div>
		  <!-- 眼睛 -->
          <div class="mouth"></div>
		  <!-- 嘴巴 -->
        </div>
        <div class="body">
			<!-- 身体 -->
          <div class="hand">
			  <!-- 手 -->
            <div class="hand-one"></div>
            <div class="hand-two"></div>
          </div>
        </div>
      </div>
      <div class="leg-one"></div>
	  <!-- 脚 -->
      <div class="leg-two"></div>
    </div>
    <div class="swing-rod"></div>
	<!-- 绳索 -->
    <div class="bottom"></div>
	<!-- 木板 -->
  </div>
  <div class="pole one"></div>
  <!-- 支撑物 -->
  <div class="pole two"></div>
</div>

样式

支撑物，众所周知建房子需要打好地基，不然房子容易坍塌，那么秋千也是如此。

.wrapper .pole {
  position: absolute;
  width: 5px;
  height: 250px;
  left: 50%;
  -webkit-transform-origin: center top;
          transform-origin: center top;
  -webkit-transform: translateX(-50%) rotate(-25deg);
          transform: translateX(-50%) rotate(-25deg);
  color: silver;
  background: currentColor;
}
.wrapper .pole.two {
  -webkit-transform: translateX(-50%) rotateY(-180deg) rotate(-25deg);
          transform: translateX(-50%) rotateY(-180deg) rotate(-25deg);
}
.wrapper .pole:before {
  content: "";
  position: absolute;
  top: -10px;
  left: -7px;
  width: 20px;
  height: 20px;
  border-radius: 100%;
  background: currentColor;
}
.wrapper .pole:after {
  content: "";
  position: absolute;
  left: 0;
  bottom: 0;
  width: 20px;
  height: 5px;
  -webkit-transform: translateX(-50%) rotate(25deg);
          transform: translateX(-50%) rotate(25deg);
  background: currentColor;
}

绳索和木板样式 连接上下部分就组合成了一个秋千

.wrapper .swing .swing-rod {
  position: absolute;
  width: 5px;
  height: 200px;
  left: 50%;
  -webkit-transform: translateX(-50%);
          transform: translateX(-50%);
  background: #323232;
}
.wrapper .swing .bottom {
  position: absolute;
  width: 100%;
  height: 5px;
  bottom: 0;
  background: saddlebrown;
}

身体部分样式，头发、刘海、眼睛、嘴巴、手等部位

.wrapper .swing .human {
  position: absolute;
  width: 40px;
  height: 80px;
  bottom: 5px;
  z-index: -1;
}
.wrapper .swing .human .top-part {
  position: absolute;
  width: 40px;
  height: 80px;
  bottom: 5px;
  -webkit-transform-origin: center bottom;
          transform-origin: center bottom;
  -webkit-animation-name: body-animation;
          animation-name: body-animation;
  -webkit-animation-duration: 0.8s;
          animation-duration: 0.8s;
  -webkit-animation-iteration-count: infinite;
          animation-iteration-count: infinite;
  -webkit-animation-timing-function: ease-in-out;
          animation-timing-function: ease-in-out;
  -webkit-animation-direction: alternate;
          animation-direction: alternate;
}
.wrapper .swing .human .top-part .head {
  position: absolute;
  bottom: 40px;
  left: 50%;
  -webkit-transform: translateX(-50%);
          transform: translateX(-50%);
  width: 20px;
  height: 20px;
  background: #d59e7b;
  border-radius: 100%;
  z-index: 2;
}
.wrapper .swing .human .top-part .head .hair {
  position: absolute;
  top: -5px;
  left: -10px;
  background: black;
  width: 22px;
  height: 44px;
  border-top-right-radius: 0%;
  border-top-left-radius: 100%;
  border-bottom-right-radius: 75%;
  border-bottom-left-radius: 10%;
  z-index: 2;
}
.wrapper .swing .human .top-part .head .fringe {
  position: absolute;
  top: -5px;
  left: 0;
  width: 0px;
  height: 0px;
  border-top: 10px solid black;
  border-bottom: 10px solid black;
  border-left: 10px solid transparent;
  border-right: 10px solid transparent;
  border-radius: 100%;
  -webkit-transform: rotate(45deg);
          transform: rotate(45deg);
}
.wrapper .swing .human .top-part .head .eye {
  content: "";
  position: absolute;
  top: 6px;
  right: 2px;
  width: 2px;
  height: 2px;
  background: black;
  border-radius: 100%;
}
.wrapper .swing .human .top-part .head .mouth {
  position: absolute;
  top: 10px;
  right: 0px;
  width: 0px;
  height: 0px;
  border-top: 3px solid transparent;
  border-bottom: 3px solid transparent;
  border-left: 3px solid transparent;
  border-right: 3px solid white;
  border-radius: 100%;
  -webkit-transform: rotate(28deg);
          transform: rotate(28deg);
}
.wrapper .swing .human .top-part .body {
  position: absolute;
  bottom: 0px;
  left: 50%;
  -webkit-transform: translateX(-50%);
          transform: translateX(-50%);
  background: #ee5130;
  width: 20px;
  height: 40px;
  border-top-left-radius: 20px;
  border-top-right-radius: 20px;
}
.wrapper .swing .human .top-part .body .hand {
  position: absolute;
  top: 20%;
  left: 10%;
}
.wrapper .swing .human .top-part .body .hand .hand-one {
  position: absolute;
  -webkit-transform: rotate(30deg);
          transform: rotate(30deg);
  width: 5px;
  height: 15px;
  background: #ee5130;
  -webkit-box-shadow: 0 -1px 0px 1px rgba(0, 0, 0, 0.2);
          box-shadow: 0 -1px 0px 1px rgba(0, 0, 0, 0.2);
  border-top-right-radius: 100%;
  border-top-left-radius: 100%;
}
.wrapper .swing .human .top-part .body .hand .hand-two {
  background: #d59e7b;
  position: absolute;
  top: 14px;
  left: -6px;
  width: 4px;
  height: 15px;
  -webkit-transform-origin: center top;
          transform-origin: center top;
  -webkit-transform: rotate(-60deg);
          transform: rotate(-60deg);
  border-top-left-radius: 15px;
}

脚部分

.wrapper .swing .human .leg-one {
  position: absolute;
  bottom: 0;
  left: 10px;
  width: 40px;
  height: 10px;
  background: #1973ad;
  border-bottom-left-radius: 20px;
  border-top-right-radius: 20px;
  z-index: -1;
}
.wrapper .swing .human .leg-two {
  position: absolute;
  width: 40px;
  height: 10px;
  bottom: 5px;
  right: -5px;
  border-top-right-radius: 50%;
  border-bottom-right-radius: 20px;
  background: #1973ad;
  -webkit-transform-origin: right center;
          transform-origin: right center;
  -webkit-transform: rotate(-90deg);
          transform: rotate(-90deg);
  -webkit-animation-name: leg-animation;
          animation-name: leg-animation;
  -webkit-animation-duration: 0.8s;
          animation-duration: 0.8s;
  -webkit-animation-iteration-count: infinite;
          animation-iteration-count: infinite;
  -webkit-animation-timing-function: ease-in-out;
          animation-timing-function: ease-in-out;
  -webkit-animation-direction: alternate;
          animation-direction: alternate;
}
.wrapper .swing .human .leg-two:after {
  content: "";
  position: absolute;
  left: -5px;
  top: -1px;
  background: silver;
  height: 18px;
  width: 5px;
  border-top-left-radius: 3px;
  border-bottom-right-radius: 50%;
}

联动部分，人在板上用力蹬以来回摆动的动画

@-webkit-keyframes swing-1 {
  from {
    -webkit-transform: rotate(-35deg);
            transform: rotate(-35deg);
  }
  to {
    -webkit-transform: rotate(35deg);
            transform: rotate(35deg);
  }
}

@keyframes swing-1 {
  from {
    -webkit-transform: rotate(-35deg);
            transform: rotate(-35deg);
  }
  to {
    -webkit-transform: rotate(35deg);
            transform: rotate(35deg);
  }
}
@-webkit-keyframes body-animation {
  from {
    -webkit-transform: rotate(-25deg);
            transform: rotate(-25deg);
  }
  to {
    -webkit-transform: rotate(20deg);
            transform: rotate(20deg);
  }
}
@keyframes body-animation {
  from {
    -webkit-transform: rotate(-25deg);
            transform: rotate(-25deg);
  }
  to {
    -webkit-transform: rotate(20deg);
            transform: rotate(20deg);
  }
}
@-webkit-keyframes leg-animation {
  from {
    bottom: 2px;
    right: -8px;
    -webkit-transform: rotate(-55deg);
            transform: rotate(-55deg);
  }
  to {
    bottom: 2px;
    right: 5px;
    -webkit-transform: rotate(-170deg);
            transform: rotate(-170deg);
  }
}
@keyframes leg-animation {
  from {
    bottom: 2px;
    right: -8px;
    -webkit-transform: rotate(-55deg);
            transform: rotate(-55deg);
  }
  to {
    bottom: 2px;
    right: 5px;
    -webkit-transform: rotate(-170deg);
            transform: rotate(-170deg);
  }
}

总结

整篇主要用到的是css的transform属性的平移,@keyframes动画的旋转,绝对定位,背景颜色,堆叠顺序,阴影,边框,以上这些内容组合成的荡秋千的女孩,谢谢观看!
