Xv6 Scheduling

Learning xv6-riscv-book Chapter 7 Scheduling

time-share the CPUs: run more processes than CPUs
transparent to user processes
multiplexing processes onto CPUs:
- illusion: each process has its own virtual CPU

Multiplexing

Switching CPU among processes:

sleep/wakeup: process waits for something in the sleep syscall
periodically forces a switch: cope with processes that compute for long periods

Illusion: each process has its own CPU.

Challenges:

How to switch from one process to another?
How to force switches in a way that transparent to user processes?
Avoid races when many CPUs switching among processes concurrently.
each core must remember which process it is executing
sleep/wakeup: give up CPU, sleep waiting for an event, wake process up: avoid races, loss wakeup notifications

Context switching

save hte old thread's CPU registers
restore previously-saved registers of the new thread
- restore sp (stack pointer) & pc (program counter): switch the executing code.

swtch (kernel/swtch.S): save and restore for a kernel thread switch: switch to scheduler

void swtch(struct context *old, struct context *new);
save and restore context (register sets, kernel/proc.h:2)
swtch does not save pc: save ra -- holds the return address from which swtch was called.
return to instructions pointed by the restored ra (the code called swtch)

Yield:

yield -> sched -> swtch -> return to code called sched: scheduler

Scheduling

Secheduler: a special thread

per CPU a scheduler
running scheduler()

scheduler:

choose a process to run
swtch to run process
eventually swtch back to scheduler
scheduler acquires switch_to_proc->lock, no release

Kernel thread gives up CPU: calls sched -> switch to scheduler

scheduler & sched: co-rountines (switch between two threads).

p->lock:

often acquires in one thread and releases it in other
- once scheduler starts to convert a RUNNABLE process to RUNNING, the lock cannot be released until the kernel thread is completely running (after the swtch, for example in yield).
- interplay between exit and wait, the machinery to avoid lost wakeups
- avoidance of races between a process exiting and other processes reading or writing its state
- ...

mycpu and myproc

struct cpu: Xv6 maintains for each CPU:

currently running process
saved registers for the CPU scheduler thread
count of nested spinlocks needed to manage interrupt disabling

RISC-V giving each CPU a hartid: stored in that CPU's tp register while in the kernel:

mstart sets tp in CPU's boot (machine mode)
usertrapret saves tp in the trampiline page (user might modify tp)
uservec restores saved tp when entering the kernel.

mycpu (kernel/proc.c):

returns a pointer to the current CPU's sturct cpu
use tp to index an array of struct cpu => find the right one.
interrupts must be disabled to run mycpu: if the thread yield and then move to a different CPU, a previously read cpuid value would no longer be correct.

myproc (kernel/proc.c):

disables interrupts
invokes mycpu
fetches current process: c->proc
enables interrupts
return a pointer to a struct proc

sleep and wakeup

sleep & wakeup: sequence coordination or conditional synchronization mechanisms:

one process to sleep waiting for an event
another process to wake it up once the event has happened.

busy waiting

struct semaphore {
  struct spinlock lock;
  int count;
};

void
V(struct semaphore *s)  // producer
{
   acquire(&s->lock);
   s->count += 1;
   release(&s->lock);
}

void
P(struct semaphore *s)  // consumer
{
   while(s->count == 0)
     ;  // repeatedly polling: busy waiting
   acquire(&s->lock);
   s->count -= 1;
   release(&s->lock);
}

expensive!

sleep/wakeup

intro sleep/wakeup

void
V(struct semaphore *s)  // producer
{
   acquire(&s->lock);
   s->count += 1;
   wakeup(s);
   release(&s->lock);
}

void
P(struct semaphore *s)  // consumer
{
   while(s->count == 0)
     sleep(s);
   acquire(&s->lock);
   s->count -= 1;
   release(&s->lock);
}

sleep(chan): sleep on a wait channel: releasing CPU.
wakeup(chan): wakes all processes sleeping on chan: sleep return.

lost wake-up problem

P found s->count == 0
V runs on another CPU: changes s->count to be nonzero
V calls wakeup: no processes sleeping -> wakeup do nothing
P continues: calles sleep: asleep waiting for a V
but one V has lost: unless luckly producer calls V again, the consumer will wait forever

To avoid this problem: move the lock acquisition in P: check count and calls sleep atomically:

void
P(struct semaphore *s)  // consumer
{
   acquire(&s->lock);
   while(s->count == 0)
     sleep(s);
   s->count -= 1;
   release(&s->lock);
}

deadlocks

However, this version also deadlocks: P holds the lock while sleeps, v will block forever waiting for the lock.

To fix this: change the interface of sleep:

pass a condition lock to sleep
sleep release this lock after process is asleep and waiting on the sleep channel.
a concurrent V will be forced to wait until P is asleep: wakeup will find the sleeping consumer.
once the consumer awake: sleep reacquires the lock before returning.

final code:

void
V(struct semaphore *s)  // producer
{
   acquire(&s->lock);
   s->count += 1;
   wakeup(s);
   release(&s->lock);
}

void
P(struct semaphore *s)  // consumer
{
   while(s->count == 0)
     sleep(s, &s->lock);
   acquire(&s->lock);
   s->count -= 1;
   release(&s->lock);
}

sleep and wakeup implement

直接看源码吧，这个挺直接的。

sleep: kernel/proc.c:529

// Atomically release lock and sleep on chan.
// Reacquires lock when awakened.
void
sleep(void *chan, struct spinlock *lk)
{
  struct proc *p = myproc();

  // Must acquire p->lock in order to
  // change p->state and then call sched.
  // Once we hold p->lock, we can be
  // guaranteed that we won't miss any wakeup
  // (wakeup locks p->lock),
  // so it's okay to release lk.

  acquire(&p->lock);  //DOC: sleeplock1
  release(lk);

  // Go to sleep.
  p->chan = chan;
  p->state = SLEEPING;

  sched();

  // Tidy up.
  p->chan = 0;

  // Reacquire original lock.
  release(&p->lock);
  acquire(lk);
}

wakeup: kernel/proc.c:560

// Wake up all processes sleeping on chan.
// Must be called without any p->lock.
void
wakeup(void *chan)
{
  struct proc *p;

  for(p = proc; p < &proc[NPROC]; p++) {
    if(p != myproc()){
      acquire(&p->lock);
      if(p->state == SLEEPING && p->chan == chan) {
        p->state = RUNNABLE;
      }
      release(&p->lock);
    }
  }
}

Pipes 实现

Pipe 是用 struct pipe 来表示的:

一个 lock
data: 环形 buffer
nread/nwrite: 已读/写的总字节数
- buffer 为空：nwrite == nread
- buffer 为满：nwrite == nread + PIPESIZE
读取 buf：data[nread % PIPESIZE]

调用接口：

pipewrite
piperead

wait, exit, kill

wait：父进程等待任一子进程退出
exit：（子）进程退出
kill：终止进程

exit 会把进程状态改为 ZOMBIE。

wait 取得 ZOMBIE 的子进程后将其状态改成 UNUSED，读取其退出状态，返回其 pid。

若父在子之前退出，父会把子转让给 init。init 漫无止境地调用 wait，所以所有就成都可以执行完后被清除。
