app功能引导页实现


1. 方案一

最简单的办法,就是让UI根据屏幕出各种尺寸的图,直接拿来用

2.方案二

UIBezierPath绘制 + 图片

实现思路: 1.创建个充满屏幕的全透明View 【GuideView】

2.创建个背景view 【bgView】,放置在GuideView上

3.开始绘制透明框等,设置bgview

4.放置图片

示例代码【重点BSLPath方法】

import UIKit

class KWGuide1View: KWView {

    override func kw_setupViews() {
        super.kw_setupViews()

        frame = CGRect(x: 0, y: 0, width: KScreenWidth, height: KScreenHeight)
        backgroundColor = .clear

        self.BSLPath()
    }



    override func kw_setupLayouts() {

        super.kw_setupLayouts()



    }


    func BSLPath() {

        let bgView = UIView(frame: CGRect(x: 0, y: 0, width: KScreenWidth, height: KScreenHeight))
        addSubview(bgView)
        //整个背景
        let bsl = UIBezierPath.init(rect: CGRect(x: 0, y: 0, width: KScreenWidth, height: KScreenHeight))
        //透明框
        let bslClear = UIBezierPath(roundedRect: CGRect(x: KScreenWidth/4*3, y: KScreenHeight-KTabBarHeight-KHomeIndicatorHeight+KHomeIndicatorHeight, width: KScreenWidth/4, height: KTabBarHeight-KHomeIndicatorHeight),cornerRadius:5).reversing()
        bsl.append(bslClear)


        let layer = CAShapeLayer()
        layer.fillColor = UIColor.init(r: 0, g: 0, b: 0, alpha: 0.7).cgColor
        layer.path = bsl.cgPath
        bgView.layer.addSublayer(layer)

        addSubview(imgv)
        imgv.snp.makeConstraints { make in
            make.size.equalTo(CGSize(width: KScreenWidth-50, height: (KScreenWidth-50)/336*487 ))
            make.right.equalTo(-15)
            make.bottom.equalTo(-KTabBarHeight)
        }



        bgView.kw.tapAtion { _ in
            self.removeFromSuperview()
            let v2 = KWGuide2View()
            UIApplication.shared.keyWindow?.addSubview(v2)
        }

    }


    private lazy var imgv:UIImageView = {
        let img = UIImageView()
        img.image = UIImage(named: "ic_yindao_1")
        img.contentMode = .scaleToFill
        return img
    }()

}
复制代码
