一、项目结构示例
注：该项目是我个人项目示例，各位可以自行命令或设计目录结构。
root@ubuntu:/SuperxonWebSite# tree
.
├── Apps
│ ├── commonConfigurationItem
│ │ └── PersonInChargeWarningInfo
│ │ └── ...
│ └── humanResources
│ └── ...
├── Assets
│ ├── ini
│ │ └── common.ini
│ └── mp4
│ └──...
├── Databases
│ └── ...
├── go.mod
├── go.sum
├── Middlewares
│ └── ...
├── Models
│ └── ProductionMaterialRelation
│ └── ...
├── Pb
│ └── user
│ └── ...
├── Router
│ └── routers.go
├── Services
│ └── kafka.go
├── main.go
└── Utils
└── ...
复制代码二、文件逐个分析
1.Apps 主体业务层，放入除数据库操作的所有的逻辑处理业务，提供给路由配置连接的函数，示例：
func GetVideoInfoListHandler(c *gin.Context) {
videoInfoList, err := FileManager.GetVideoInfoList() //这段代码就是在调取封装好的数据库操作
if err != nil {
c.JSON(http.StatusNotFound, gin.H{"error": err.Error()})
} else {
c.JSON(http.StatusOK, videoInfoList)
}
}
复制代码2.Assets 资源层，放入的是配置文件、外部文件和保存上传的文件，当然也可以把这三部分拆分出来。
3.Databases 数据库的初始化连接层，放入的是各类数据库连接文件，例如：
mysql.go
package Databases
import (
"fmt"
_ "github.com/go-sql-driver/mysql"
_ "github.com/jinzhu/gorm/dialects/mysql"
"github.com/jmoiron/sqlx"
)
var SuperxonUserDb *sqlx.DB
func InitMysql() error {
var err error
SuperxonUserDb, err = sqlx.Open("mysql", "username:password@(172.20.3.12:3306)/superxon-user?charset=utf8mb4&parseTime=true&loc=Local")
if err != nil {
fmt.Println("open superxon-user failed,", err)
return err
}
SuperxonUserDb.SetMaxIdleConns(5)
SuperxonUserDb.SetMaxOpenConns(15)
return nil
}
func CloseMysql() {
_ = SuperxonUserDb.Close()
}
复制代码4.Middlewares 中间件层，放入的就是自定义的中间件，例如：
package Middlewares
import (
"context"
"github.com/gin-gonic/gin"
"net/http"
"time"
)
func TimeoutMiddleware(timeout time.Duration) func(c *gin.Context) {
return func(c *gin.Context) {
// wrap the request context with a timeout
ctx, cancel := context.WithTimeout(c.Request.Context(), timeout)
defer func() {
// check if context timeout was reached
if ctx.Err() == context.DeadlineExceeded {
// write response and abort the request
c.Writer.WriteHeader(http.StatusGatewayTimeout)
c.Abort()
}
//cancel to clear resources after finished
cancel()
}()
// replace request with context wrapped request
c.Request = c.Request.WithContext(ctx)
c.Next()
}
}
复制代码5.Models 数据库模型操作层，对数据库CRUD的处理都在这里，示例：
package UserRelation
import (
"SuperxonWebSite/Databases"
"errors"
)
type RightManager struct {
Id int64 `db:"id"`
Username string `db:"username"`
Nickname string `db:"nickname"`
RightItem string `db:"right_item"`
}
func FindAllRightManager() ([]RightManager, error) {
var res = make([]RightManager, 0)
sqlStr := "SELECT * FROM right_manager"
err := Databases.SuperxonUserDb.Select(&res, sqlStr)
if err != nil {
return nil, err
}
return res, nil
}
复制代码6.Pb grpc微服务 *.pb.go文件的存放点。
7.Router 放入路由配置文件 routers.go。
8.Services 放入的是其它服务组件的初始化等等，例如kafka.go。
package Services
import (
"encoding/json"
"errors"
"github.com/tal-tech/go-queue/kq"
"time"
)
var EmailOfWaringInfoKqPusher *kq.Pusher
var EmailOfWaringInfoWithStationKqPusher *kq.Pusher
var EmailOfPtrChangeInfoKqPusher *kq.Pusher
func KafkaInit() {
EmailOfWaringInfoKqPusher = kq.NewPusher([]string{"172.20.3.19:9092", "172.20.3.19:9093", "172.20.3.19:9094"}, "EmailOfWarningInfo")
EmailOfWaringInfoWithStationKqPusher = kq.NewPusher([]string{"172.20.3.19:9092", "172.20.3.19:9093", "172.20.3.19:9094"}, "EmailOfWarningInfoWithStation")
EmailOfPtrChangeInfoKqPusher = kq.NewPusher([]string{"172.20.3.19:9092", "172.20.3.19:9093", "172.20.3.19:9094"}, "EmailOfPtrChangedInfo")
}
复制代码
