# 【TSP】基于matlab免疫算法求解31城市旅行商问题【含Matlab源码 1149期】

·  阅读 177

## 三、源代码

``````%%%%%%%%%%%%%%%%%%%%%%%免疫算法求解决TSP问题%%%%%%%%%%%%%%%%%%%%%%
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%初始化%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
clear all;                        %清除所有变量
close all;                        %清图
clc;                              %清屏
C=[1304 2312;3639 1315;4177 2244;3712 1399;3488 1535;3326 1556;...
3238 1229;4196 1044;4312  790;4386  570;3007 1970;2562 1756;...
2788 1491;2381 1676;1332  695;3715 1678;3918 2179;4061 2370;...
3780 2212;3676 2578;4029 2838;4263 2931;3429 1908;3507 2376;...
3394 2643;3439 3201;2935 3240;3140 3550;2545 2357;2778 2826;...
2370 2975];                  %31个省会城市坐标
N=size(C,1);                     %TSP问题的规模,即城市数目
D=zeros(N);                      %任意两个城市距离间隔矩阵
%%%%%%%%%%%%%%%%%%%%%求任意两个城市距离间隔矩阵%%%%%%%%%%%%%%%%%%%%%
for i=1:N
for j=1:N
D(i,j)=((C(i,1)-C(j,1))^2+(C(i,2)-C(j,2))^2)^0.5;
end
end
NP=200;                           %免疫个体数目
G=1000;                           %最大免疫代数
f=zeros(N,NP);                    %用于存储种群
for i=1:NP
f(:,i)=randperm(N);           %随机生成初始种群
end
len=zeros(NP,1);                  %存储路径长度
for i=1:NP
len(i)=func3(D,f(:,i),N);     %计算路径长度
end
[Sortlen,Index]=sort(len);
Sortf=f(:,Index);                 %种群个体排序
gen=0;                            %免疫代数
Ncl=10;                            %克隆个数
%%%%%%%%%%%%%%%%%%%%%%%%%%%免疫循环%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
while gen<G
for i=1:NP/2
%%%%%%%%%%%%选激励度前NP/2个体进行免疫操作%%%%%%%%%%%%%%%
a=Sortf(:,i);
Ca=repmat(a,1,Ncl);
for j=1:Ncl
p1=floor(1+N*rand());
p2=floor(1+N*rand());
while p1==p2
p1=floor(1+N*rand());
p2=floor(1+N*rand());
end
tmp=Ca(p1,j);
Ca(p1,j)=Ca(p2,j);
Ca(p2,j)=tmp;
end
Ca(:,1)=Sortf(:,i);            %保留克隆源个体
%%%%%%%%%%%%克隆抑制，保留亲和度最高的个体%%%%%%%%%%%%%%
for j=1:Ncl
Calen(j)=func3(D,Ca(:,j),N);
end
[SortCalen,Index]=sort(Calen);

af(:,i)=SortCa(:,1);
alen(i)=SortCalen(1);
end
%%%%%%%%%%%%%%%%%%%%%%%%%%种群刷新%%%%%%%%%%%%%%%%%%%%%%%%%%
for i=1:NP/2

blen(i)=func3(D,bf(:,i),N);   %计算路径长度
end
%%%%%%%%%%%%%%%%%%%%免疫种群与新种群合并%%%%%%%%%%%%%%%%%%%%%
f=[af,bf];
len=[alen,blen];
[Sortlen,Index]=sort(len);
Sortf=f(:,Index);
gen=gen+1;
trace(gen)=Sortlen(1);
end
