前端新手指南功能实现(driver.js、vue-tour 、Intro.js)

4,727 阅读2分钟

最近产品提出要在项目中添加新手指引功能,经过查询资料发现3个插件可行。

1.vue-tour组件

pulsardev.github.io/vue-tour/?f…

2.Intro.js

www.dowebok.com/demo/2013/3…

3.driver.js

codechina.csdn.net/mirrors/kam…

driver.js 可以根据参数自行配置自己想要的效果,和市面上的其他新手指引相似 也比较接近产品经理的需求 效果图如下:


使用过程中出现的坑:

由于新手指引要在2个页面使用 所有如果第二个页面没有完成或者跳过新手指南,通过浏览器返回上一个页面,则第二个页面的新手指南会出现在返回的页面上。 解决方法: 在beforeDestory生命周期里,把新手指引调用一个关闭的功能;(注意不是调用配置里的onReset的方法)

 showNewUserHelp() {
      this.controlDriver = new Driver({
        className: 'scoped-class', // className to wrap driver.js popover
        animate: true, // Animate while changing highlighted element
        opacity: 0.5, // Background opacity (0 means only popovers and without overlay)
        padding: 0, // Distance of element from around the edges
        allowClose: false, // Whether clicking on overlay should close or not
        overlayClickNext: false, // Should it move to next step on overlay click
        doneBtnText: '完成', // Text on the final button
        closeBtnText: '跳过', // Text on the close button for this step
        nextBtnText: '下一步', // Next button text for this step
        prevBtnText: '上一步', // Previous button text for this step
        showButtons: true, // Do not show control buttons in footer
        keyboardControl: false, // Allow controlling through keyboard
        scrollIntoViewOptions: {}, // We use `scrollIntoView()`
        onHighlightStarted: (Element) => {}, // Called when element is about to be highlighted
        onHighlighted: (Element) => {}, // Called when element is fully highlighted
        onDeselected: (Element) => {}, // Called when element has been deselected
        onReset: (Element) => { this.updateProfile(); }, //  when overlay is about to be cleared
        onNext: (Element) => { }, // Called when moving to next step on any steps
        onPrevious: (Element) => { }, // Called when moving to next step on any step
      });
      this.controlDriver.defineSteps([
        {
          element: '#item0',
          popover: {
            title: '11 (1/4)',
            description: '11。',
            position: 'bottom',
          },
        },
        {
          element: '#item1',
          popover: {
            title: '22 (2/4)',
            description: '22。',
            position: 'bottom',
          },
        },
        {
          element: '#item2',
          popover: {
            title: '33 (3/4)',
            description: '33',
            position: 'bottom',
          },
        },
        {
          element: '#item3',
          popover: {
            title: '44(4/4)',
            description: '44',
            position: 'bottom',
          },
        },
      ]);
      this.controlDriver.start();
    },
      updateProfile() {
      const params = {
        isNavigationGuide: true,
      };
      updateUserInfo(params)
        .then((res) => {
          this.setProfile(res.data);
        });
    },

  beforeDestroy() {
    if (!this.controlDriver) {
      return;
    }
    this.controlDriver.options.onReset = null;
    this.controlDriver.reset();
  },

源码


  /**
   * Resets the steps if any and clears the overlay
   * @param {boolean} immediate
   * @public
   */
  reset(immediate = false) {
    this.currentStep = 0;
    this.isActivated = false;
    this.overlay.clear(immediate);
  }
  /**
   * Removes the overlay and cancel any listeners
   * @public
   */
  clear(immediate = false) {
    // Callback for when overlay is about to be reset
    if (this.options.onReset) {
      this.options.onReset(this.highlightedElement);
    }

    // Deselect the highlighted element if any
    if (this.highlightedElement) {
      const hideStage = true;
      this.highlightedElement.onDeselected(hideStage);
    }

    this.highlightedElement = null;
    this.lastHighlightedElement = null;

    if (!this.node) {
      return;
    }

    // Clear any existing timers and remove node
    this.window.clearTimeout(this.hideTimer);

    if (this.options.animate && !immediate) {
      this.node.style.opacity = '0';
      this.hideTimer = this.window.setTimeout(this.removeNode, ANIMATION_DURATION_MS);
    } else {
      this.removeNode();
    }
  }

2.当点击新手指引的高亮部分时,会出现高亮的文字不显示。 解决办法: 禁止高亮的地方点击,加上css禁止成为事件点击对象

.driver-highlighted-element {
  pointer-events: none;
}
