Spark 提交任务 源码解析 (一)

这是我参与更文挑战的第10天,活动详情查看:更文挑战

最令人头秃的就是看源码


环境

  • 本次使用的spark版本是 3.0.0
<dependency>
    <groupId>org.apache.spark</groupId>
    <artifactId>spark-core_2.12</artifactId>
    <version>3.0.0</version>
</dependency>
<dependency>
    <groupId>org.apache.spark</groupId>
    <artifactId>spark-yarn_2.12</artifactId>
    <version>3.0.0</version>
    <scope>provided</scope>
</dependency>
复制代码

1.这是我们提交任务的脚本

bin/spark-submit \
--class org.apache.spark.examples.SparkPi \
--master yarn \
--deploy-mode client \
./examples/jars/spark-examples_2.12-3.0.0.jar
复制代码

2.咱们看下 spark-submit 脚本代码

if [ -z "${SPARK_HOME}" ]; then
  source "$(dirname "$0")"/find-spark-home
fi
# disable randomized hash for string in Python 3.3+
export PYTHONHASHSEED=0
# 重点代码
exec "${SPARK_HOME}"/bin/spark-class org.apache.spark.deploy.SparkSubmit "$@"
复制代码

可以看出 脚本中执行了 spark-class 脚本 ,参数为:org.apache.spark.deploy.SparkSubmit "$@"

3.继续跟踪 spark-class 脚本代码

# 下方是部分源码

# 找到最后的代码 看到执行了CMD的值
CMD=("${CMD[@]:0:$LAST}")
exec "${CMD[@]}"

# 接下来找到CMD是那来的?
# 下面代码是组装参数
CMD=()
DELIM=$'\n'
CMD_START_FLAG="false"
while IFS= read -d "$DELIM" -r ARG; do
  if [ "$CMD_START_FLAG" == "true" ]; then
    CMD+=("$ARG")
  else
    if [ "$ARG" == $'\0' ]; then
      # After NULL character is consumed, change the delimiter and consume command string.
      DELIM=''
      CMD_START_FLAG="true"
    elif [ "$ARG" != "" ]; then
      echo "$ARG"
    fi
  fi
done < <(build_command "$@")
# 这里调用了 build_command 方法

# -Xmx128m 是不是很熟悉,这里拼接成了一个Java启动命令
# 通过运行这个类 org.apache.spark.launcher.Main 拼接好启动命令
build_command() {
  "$RUNNER" -Xmx128m $SPARK_LAUNCHER_OPTS -cp "$LAUNCH_CLASSPATH" org.apache.spark.launcher.Main "$@"
  printf "%d\0" $?
}

# 拼接完启动命令后由 exec "${CMD[@]}" 来执行

复制代码

org.apache.spark.launcher.Main 一大堆骚操作之后,会生成启动命令,命令会运行 org.apache.spark.deploy.SparkSubmit


4.接下来看 org.apache.spark.deploy.SparkSubmit

  • 我们先找到 main 方法
  override def main(args: Array[String]): Unit = {
    //这里声明了一个匿名内部类
    val submit = new SparkSubmit() {
      .......
    }
    //调用匿名内部类方法
    submit.doSubmit(args)
  }
复制代码
  • 接下来看 SparkSubmit 匿名内部类 里做了什么
    • 重写了 parseArguments 在调用父类doSubmit后,会被调用
    • doSubmit被调用后会调用父类的doSubmit
val submit = new SparkSubmit() {
    self =>
    //这里重写了 parseArguments 在调用父类doSubmit后,会被调用
    override protected def parseArguments(args: Array[String]): SparkSubmitArguments = {
        new SparkSubmitArguments(args) {
            override protected def logInfo(msg: => String): Unit = self.logInfo(msg)
            override protected def logWarning(msg: => String): Unit = self.logWarning(msg)
            override protected def logError(msg: => String): Unit = self.logError(msg)
        }
    }
    override protected def logInfo(msg: => String): Unit = printMessage(msg)
    override protected def logWarning(msg: => String): Unit = printMessage(s"Warning: $msg")
    override protected def logError(msg: => String): Unit = printMessage(s"Error: $msg")
    //doSubmit被调用后会调用父类的doSubmit
    override def doSubmit(args: Array[String]): Unit = {
        try {
            super.doSubmit(args)
        } catch {
            case e: SparkUserAppException =>
                exitFn(e.exitCode)
        }
    }
}
复制代码
  def doSubmit(args: Array[String]): Unit = {
    val uninitLog = initializeLogIfNecessary(true, silent = true)
    // parseArguments 调用了上方 匿名内部类 重写的方法
    val appArgs = parseArguments(args)
    if (appArgs.verbose) {
      logInfo(appArgs.toString)
    }
    appArgs.action match {
      case SparkSubmitAction.SUBMIT => submit(appArgs, uninitLog)
      case SparkSubmitAction.KILL => kill(appArgs)
      case SparkSubmitAction.REQUEST_STATUS => requestStatus(appArgs)
      case SparkSubmitAction.PRINT_VERSION => printVersion()
    }
  }
复制代码
  • parseArguments 方法做了什么尼?它创建了 SparkSubmitArguments 用来解析参数
  • 看看SparkSubmitArguments关键源码
// 由于scala会把类中所有代码都走一便,有几百行,就不一一逼逼了
// 直接找到108行
  parse(args.asJava)

//这方法主要是解析参数  类如 --class --master 啥的
//其中 handle 是重点 ,其他都是解析字符串啥的
protected def parse(args: util.List[String]): Unit = {
    val eqSeparatedOpt = Pattern.compile("(--[^=]+)=(.+)")
    var idx = 0
    idx = 0
    while ( {
        idx < args.size
    }) {
        var arg = args.get(idx)
        var value = null
        val m = eqSeparatedOpt.matcher(arg)
        if (m.matches) {
            arg = m.group(1)
            value = m.group(2)
        }
        var name = findCliOption(arg, opts)
        if (name != null) {
            if (value == null) {
                if (idx == args.size - 1) throw new IllegalArgumentException(String.format("Missing argument for option '%s'.", arg))
                idx += 1
                value = args.get(idx)
            }
            // 重点方法 handle
            if (!handle(name, value)) break
            continue
        }
        name = findCliOption(arg, switches)
        if (name != null) {
            if (!handle(name, null)) break
            continue
        }
        if (!handleUnknown(arg)) break

        idx += 1
    }
    if (idx < args.size) idx += 1
    handleExtraArgs(args.subList(idx, args.size))
}

//handle方法是父类定义的 在 `SparkSubmitArguments` 重写
//父类代码
protected boolean handle(String opt, String value) {
  //这种直接抛异常的,基本都是需要子类重写,直接找子类就行
throw new UnsupportedOperationException();
}
//子类代码 在 `SparkSubmitArguments`中
override protected def handle(opt: String, value: String): Boolean = {
opt match {
  case NAME =>
    name = value
    //--master
  case MASTER =>
    master = value
    //--class
  case CLASS =>
    mainClass = value

  case DEPLOY_MODE =>
    if (value != "client" && value != "cluster") {
      error("--deploy-mode must be either \"client\" or \"cluster\"")
    }
    deployMode = value
  //此处省略一些代码,很多参数,具体可自行查看
  case _ =>
    error(s"Unexpected argument '$opt'.")
}
action != SparkSubmitAction.PRINT_VERSION
}

复制代码


  • 接下来我们继续看没有执行完的 doSubmit
  def doSubmit(args: Array[String]): Unit = {
    val uninitLog = initializeLogIfNecessary(true, silent = true)
    // 上面讲述了 parseArguments 都做了些啥
    val appArgs = parseArguments(args)
    if (appArgs.verbose) {
      logInfo(appArgs.toString)
    }
    // 接下来继续
    // 这里用的了模式匹配
    // 默认情况下啥 SUBMIT (为啥默认SUBMIT,去 SparkSubmitArguments 看,在227行: action = Option(action).getOrElse(SUBMIT))
    // 可以穿参数 指定
    appArgs.action match {
        //接下来走 submit方法
      case SparkSubmitAction.SUBMIT => submit(appArgs, uninitLog)
      case SparkSubmitAction.KILL => kill(appArgs)
      case SparkSubmitAction.REQUEST_STATUS => requestStatus(appArgs)
      case SparkSubmitAction.PRINT_VERSION => printVersion()
    }
  }
复制代码

5.submit(appArgs, uninitLog)

  private def submit(args: SparkSubmitArguments, uninitLog: Boolean): Unit = {

    def doRunMain(): Unit = {
      if (args.proxyUser != null) {
        //我们参数没指定,所以走else,代码省略。。。可自行查看
      } else {
        runMain(args, uninitLog)
      }
    }

    if (args.isStandaloneCluster && args.useRest) {
      //Standalone提交方式
      //代码省略。。。
    } else {
      //我们这里使用yarn 所以走else
      //这里会调用上面的doRunMain
      doRunMain()
    }
  }
复制代码

进入runMain 方法,只保留关键代码,全部自己行查看

private def runMain(args: SparkSubmitArguments, uninitLog: Boolean): Unit = {
    //执行完下面这行代码得到 childMainClass="org.apache.spark.deploy.yarn.YarnClusterApplication"
    val (childArgs, childClasspath, sparkConf, childMainClass) = prepareSubmitEnvironment(args)
    ......
    //这里是获取spark运行环境,用来给yarn发送用
    val loader = getSubmitClassLoader(sparkConf)
    for (jar <- childClasspath) {
      addJarToClasspath(jar, loader)
    }
    ......
    //这里拿到 org.apache.spark.deploy.yarn.YarnClusterApplication 的 class
    var mainClass: Class[_] = null
    try {
      mainClass = Utils.classForName(childMainClass)
    } catch {
      ......
    }
    //这里判断 mainClass 是否继承了 SparkApplication
    //YarnClusterApplication 继承了 SparkApplication
    val app: SparkApplication = if (classOf[SparkApplication].isAssignableFrom(mainClass)) {
      //所以会走这里 创建YarnClusterApplication对象
      mainClass.getConstructor().newInstance().asInstanceOf[SparkApplication]
    } else {
      new JavaMainApplication(mainClass)
    }
    .........
    try {
      //启动
      app.start(childArgs.toArray, sparkConf)
    } catch {
      case t: Throwable =>
        throw findCause(t)
    }
}

//这方法几百行省略了一些
private[deploy] def prepareSubmitEnvironment(
      args: SparkSubmitArguments,
      conf: Option[HadoopConfiguration] = None)
      : (Seq[String], Seq[String], SparkConf, String) = {
    .......

    //重点 关注 YARN_CLUSTER_SUBMIT_CLASS
    //private[deploy] val YARN_CLUSTER_SUBMIT_CLASS ="org.apache.spark.deploy.yarn.YarnClusterApplication"

    // In yarn-cluster mode, use yarn.Client as a wrapper around the user class
    if (isYarnCluster) {
    //取 常量 YARN_CLUSTER_SUBMIT_CLASS
    //可得 childMainClass="org.apache.spark.deploy.yarn.YarnClusterApplication"
      childMainClass = YARN_CLUSTER_SUBMIT_CLASS
      ......
    }
    .......
    (childArgs, childClasspath, sparkConf, childMainClass)
}

复制代码

6. 接下来 YarnClusterApplicationstart 方法

肝不动了,等第二章.....很快
