OkHttp枯燥无趣的源码分析

·  阅读 808

摘要

本文主要是分析Android主流网络请求框架OkHttp源码,看看每天都在打交道的伙计在到底干了什么。它为了我们处理了网络中最根本的HTTP问题,如HTTP请求报文和响应报文的处理。允许我们自定义拦截器实现自己的功能,如日志打印,增加请求头等。默认六个拦截器处理网络请求,缓存复用,连接复用,数据转化,重试恢复机制。

请求

OkHttp的异步请求主要了调用Call对象的enqueue函数,而Call接口唯一的实现类是RealCall。所以异步请求主要是调用了RealCallenqueue函数,而同步请求则是RealCall对象的execute函数。

RealCall的enqueue与execute函数

下面先分析异步请求:

//RealCall
override fun enqueue(responseCallback: Callback) {
    check(executed.compareAndSet(false, true)) { "Already Executed" }

    callStart()
    client.dispatcher.enqueue(AsyncCall(responseCallback))
  }
复制代码

RealCall调用Dispatcher的enqueue函数

//Dispatcher
internal fun enqueue(call: AsyncCall) {
    synchronized(this) {
      readyAsyncCalls.add(call)
      if (!call.call.forWebSocket) {
        val existingCall = findExistingCallWithHost(call.host)
        if (existingCall != null) call.reuseCallsPerHostFrom(existingCall)
      }
    }
    promoteAndExecute()
}
复制代码

readyAsyncCalls是一个队列,用于保存即将执行的AsyncCall

  private fun promoteAndExecute(): Boolean {
    this.assertThreadDoesntHoldLock()

    val executableCalls = mutableListOf<AsyncCall>()
    val isRunning: Boolean
    synchronized(this) {
      val i = readyAsyncCalls.iterator()
      while (i.hasNext()) {
        val asyncCall = i.next()
		//maxRequests默认最大网络请求数 64
        if (runningAsyncCalls.size >= this.maxRequests) break // Max capacity.
        //maxRequestsPerHost默认最大目的主机请求数5
        if (asyncCall.callsPerHost.get() >= this.maxRequestsPerHost) continue // Host max capacity.

        i.remove()
        asyncCall.callsPerHost.incrementAndGet()
        executableCalls.add(asyncCall)
        runningAsyncCalls.add(asyncCall)
      }
      isRunning = runningCallsCount() > 0//待运行+正在运行主机数
    }

    for (i in 0 until executableCalls.size) {
      val asyncCall = executableCalls[i]
      //调用AsyncCall
      asyncCall.executeOn(executorService)
    }

    return isRunning
  }
复制代码

runningAsyncCalls 是一个队列,保存正在执行AsyncCallpromoteAndExecute()函数主要将readyAsyncCalls队列中待运行的请求添加到runningAsyncCalls队列中,并调用其executeOn函数。

    fun executeOn(executorService: ExecutorService) {
      client.dispatcher.assertThreadDoesntHoldLock()

      var success = false
      try {
          //将AsyncCall添加到线程池中
        executorService.execute(this)
        success = true
      } catch (e: RejectedExecutionException) {
        val ioException = InterruptedIOException("executor rejected")
        ioException.initCause(e)
        noMoreExchanges(ioException)
        responseCallback.onFailure(this@RealCall, ioException)
      } finally {
        if (!success) {
          client.dispatcher.finished(this) // This call is no longer running!
        }
      }
    }
复制代码

executeOn函数主要讲AsyncCall添加到线程池中。那么到这里就要看看AsyncCallrun函数了,看看如何实现。

override fun run() {
  threadName("OkHttp ${redactedUrl()}") {
    var signalledCallback = false
    timeout.enter()
    try {
      //在这里返回了响应数据
      val response = getResponseWithInterceptorChain()
      signalledCallback = true
      responseCallback.onResponse(this@RealCall, response)
    } catch (e: IOException) {
      if (signalledCallback) {
        // Do not signal the callback twice!
        Platform.get().log("Callback failure for ${toLoggableString()}", Platform.INFO, e)
      } else {
        responseCallback.onFailure(this@RealCall, e)
      }
    } catch (t: Throwable) {
      cancel()
      if (!signalledCallback) {
        val canceledException = IOException("canceled due to $t")
        canceledException.addSuppressed(t)
        responseCallback.onFailure(this@RealCall, canceledException)
      }
      throw t
    } finally {
      client.dispatcher.finished(this)
    }
  }
}
}
复制代码

run函数,通过getResponseWithInterceptorChain()函数返回了响应数据,可见在该函数里面进行了网络请求。

再回到同步请求中,即调用realCallexecute函数。

  override fun execute(): Response {
    check(executed.compareAndSet(false, true)) { "Already Executed" }

    timeout.enter()
    callStart()
    try {
      client.dispatcher.executed(this)
      return getResponseWithInterceptorChain()
    } finally {
      client.dispatcher.finished(this)
    }
  }
复制代码

可见,同步请求直接调用了getResponseWithInterceptorChain()函数,而不是交给线程池去执行。因此同步请求 的时候记得切换到子线程执行。

getResponseWithInterceptorChain

  @Throws(IOException::class)
  internal fun getResponseWithInterceptorChain(): Response {
    // Build a full stack of interceptors.
    val interceptors = mutableListOf<Interceptor>()
    interceptors += client.interceptors
    interceptors += RetryAndFollowUpInterceptor(client)
    interceptors += BridgeInterceptor(client.cookieJar)
    interceptors += CacheInterceptor(client.cache)
    interceptors += ConnectInterceptor
    if (!forWebSocket) {
      interceptors += client.networkInterceptors
    }
    interceptors += CallServerInterceptor(forWebSocket)

    val chain = RealInterceptorChain(
        call = this,
        interceptors = interceptors,
        index = 0,
        exchange = null,
        request = originalRequest,
        connectTimeoutMillis = client.connectTimeoutMillis,
        readTimeoutMillis = client.readTimeoutMillis,
        writeTimeoutMillis = client.writeTimeoutMillis
    )

    var calledNoMoreExchanges = false
    try {
      val response = chain.proceed(originalRequest)
      if (isCanceled()) {
        response.closeQuietly()
        throw IOException("Canceled")
      }
      return response
    } catch (e: IOException) {
      calledNoMoreExchanges = true
      throw noMoreExchanges(e) as Throwable
    } finally {
      if (!calledNoMoreExchanges) {
        noMoreExchanges(null)
      }
    }
  }
复制代码

getResponseWithInterceptorChain()函数先是将我们自定义的拦截器和默认的拦截器添加到集合中,并创建RealInterceptorChain对象chain,即所谓的拦截链。然后调用chain.proceed(originalRequest)返回响应数据。每一个拦截器都会实现自己特定的功能,并在自己的重载的intercept函数中调用chain.proceed(request)调用下一个拦截器的intercept函数。这里request已经不再是原始的originalRequest,而且经过当前拦截器改造,假如需要的话。先不管每个拦截器分做了什么,大概就知道了拦截链的调用图。

未命名绘图

拦截链

在OkHttp中,最重要的是拦截链中每个拦截器的工作。例如发起网络请求的CallServerInterceptor,网络连接的ConnectInterceptor,缓存策略的CacheInterceptor,桥接模式的BridgeInterceptor,重试恢复的RetryAndFollowUpInterceptor。以及我们自定义的Interceptor,可以用来打印日志等。从它们在拦截链的不同位置,以及所做的事情,我们可以进一步定制自定义的Interceptor。

网络请求:CallServerInterceptor

那么,我们假装所有拦截器都会调用下一个拦截器,直到最后的CallServerInterceptor拦截器。作为拦截链最后一个拦截器,只重写了intercept函数,并进行真正的网络请求。

  @Throws(IOException::class)
  override fun intercept(chain: Interceptor.Chain): Response {
    val realChain = chain as RealInterceptorChain
    val exchange = realChain.exchange!!
    val request = realChain.request
    val requestBody = request.body
    val sentRequestMillis = System.currentTimeMillis()

    exchange.writeRequestHeaders(request)

    var invokeStartEvent = true
    var responseBuilder: Response.Builder? = null
      //除了head+get,其他返回false,因为其他需要请求体
    if (HttpMethod.permitsRequestBody(request.method) && requestBody != null) {
      //客户端请求头携带"Expect: 100-continue"表示告诉服务器,客户端有一个期望值(例如请求体很大),希望得到服务器能否妥善处理该请求,响应报文状态码:100能417不能
      if ("100-continue".equals(request.header("Expect"), ignoreCase = true)) {
        exchange.flushRequest()
        //responseBuilder=null表示服务器能处理
        responseBuilder = exchange.readResponseHeaders(expectContinue = true)
        exchange.responseHeadersStart()
        invokeStartEvent = false
      }
      if (responseBuilder == null) {
        if (requestBody.isDuplex()) {
          //Http 2.0全双工,发送请求,并将请求体写到底层TCP发送缓存
          exchange.flushRequest()
          val bufferedRequestBody = exchange.createRequestBody(request, true).buffer()
          requestBody.writeTo(bufferedRequestBody)
        } else {
          //服务器能处理`"Expect: 100-continue"`期望,将请求体写到底层TCP发送缓存
          val bufferedRequestBody = exchange.createRequestBody(request, false).buffer()
          requestBody.writeTo(bufferedRequestBody)
          bufferedRequestBody.close()
        }
      } else {
        exchange.noRequestBody()
        if (!exchange.connection.isMultiplexed) {
           //非100-continue情况下,防止HTTP/1.1的使用
          exchange.noNewExchangesOnConnection()
        }
      }
    } else {
      exchange.noRequestBody()
    }

    if (requestBody == null || !requestBody.isDuplex()) {
      exchange.finishRequest()
    }
    //开始获取响应头
    if (responseBuilder == null) {
      responseBuilder = exchange.readResponseHeaders(expectContinue = false)!!
      if (invokeStartEvent) {
        exchange.responseHeadersStart()
        invokeStartEvent = false
      }
    }
    var response = responseBuilder
        .request(request)
        .handshake(exchange.connection.handshake())
        .sentRequestAtMillis(sentRequestMillis)
        .receivedResponseAtMillis(System.currentTimeMillis())
        .build()
    var code = response.code
    //服务器响应:Expect:100-continue
    if (code == 100) {
	  //重新读取响应头
      responseBuilder = exchange.readResponseHeaders(expectContinue = false)!!
      if (invokeStartEvent) {
        exchange.responseHeadersStart()
      }
      response = responseBuilder
          .request(request)
          .handshake(exchange.connection.handshake())
          .sentRequestAtMillis(sentRequestMillis)
          .receivedResponseAtMillis(System.currentTimeMillis())
          .build()
      code = response.code
    }
	//响应头读取结束
    exchange.responseHeadersEnd(response)

    response = if (forWebSocket && code == 101) {
      // 表示服务器支持协议升级,切换到websocket或者HTTP 2。
      response.newBuilder()
          .body(EMPTY_RESPONSE)
          .build()
    } else {
      response.newBuilder()
          .body(exchange.openResponseBody(response)) //获取响应数据真正地方
          .build()
    }
    if ("close".equals(response.request.header("Connection"), ignoreCase = true) ||
        "close".equals(response.header("Connection"), ignoreCase = true)) {
      exchange.noNewExchangesOnConnection()//关闭连接
    }
    if ((code == 204 || code == 205) && response.body?.contentLength() ?: -1L > 0L) {
      throw ProtocolException(
          "HTTP $code had non-zero Content-Length: ${response.body?.contentLength()}")
    }
    return response
  }
复制代码

整块代码看下来,主要是为了区别下面几种情况:

  • Expect:100-continue: 客户端请求报文携带该请求头字段,表示期望服务器能处理客户端的某个期望,例如大报文。如果能满足该条件,服务器则返回状态码是100的响应报文。

    OKHttp的处理是,如果满足该条件,直接发送请求,开始等待服务器响应,若服务器支持,则直接将请求报文数据写到发送缓存中。

  • 全双工 HTTP2.0:因为目前HTTP中只有2.0版本支持全双工,全双工的过程中,请求报文与响应报文的传输会有交差的情况,HTTP/1.1 半双工不存在这种情况。

    OKHttp的处理是,如果满足该条件,直接发送请求,开始等待服务器响应,若服务器支持,则直接将请求报文数据写到发送缓存中。

  • 一般情况:直接调用exchange.noRequestBody()进行请求。

最后通过根据响应头判断是否需要协议升级,否则通过exchange.openResponseBody(response)获取响应数据部分。

所以大概流程就是:

//发送请求
exchange.flushRequest()
//写请求数据部分
val bufferedRequestBody = exchange.createRequestBody(request, true).buffer()
requestBody.writeTo(bufferedRequestBody)
//结束请求
exchange.finishRequest()
//开始读取响应头
exchange.responseHeadersStart()
//读取响应头
exchange.readResponseHeaders(expectContinue = false)!!
//结束读取响应头
exchange.responseHeadersEnd(response)
//读取响应体
exchange.openResponseBody(response)
复制代码

而在正常获得响应数据后,回调Callback对象的onResponse函数。到此,整个过程也就结束了。

连接复用:ConnectInterceptor

ConnectInterceptor连接拦截器的intercept函数非常简单,但却涉及到OkHttp的一个重要概念,连接复用。众所周知,HTTP是基于运输层的TCP协议(HTTP/3将基于UDP协议),意味着TCP三次握手建立连接和4次挥手断开连接,以及拥塞机制的慢启动阶段,影响到APP的从服务器获取数据速度。通过TCP连接的复用,降低时延和提高资源利用率。

  override fun intercept(chain: Interceptor.Chain): Response {
    val realChain = chain as RealInterceptorChain
    val exchange = realChain.call.initExchange(chain)
    val connectedChain = realChain.copy(exchange = exchange)
    return connectedChain.proceed(realChain.request)
  }
复制代码

intercept函数中最重要的代码realChain.call.initExchange(chain),创建或复用一条TCP连接进行HTTP请求或响应。这里有条调用链:

RealCall.initExchange->ExchangeFinder.find->ExchangeFinder.findHealthyConnection
->ExchangeFinder.findConnection
复制代码

findConnection函数中,查找可用的连接的步骤:

  1. 复用当前请求RealCall的连接。如果当前RealCall携带的连接connection不为null,且端口号与主机与当前主机请求一致。判断是否有其他请求call在该connection与服务器交互,没有的情况下通知连接池释放该连接,并返回Socket,并复用该connection
  2. 在连接池中寻找。遍历连接池中所有的connection,通过connection.isEligible来判断是否可以复用该connectionisEligible函数会检查很多东西,例如域名、域名、代理、DNS等等是否一致。甚至HTTP/2的connect的一些要求,例如证书。
  3. 创建新的连接。如果在前两步没有找到合适的connection,只能创建新的connection了。在创建新的连接前,还会在创建路由后,再尝试在连接池中寻找合适的connection。否则会为当前请求call创建新的connection并添加在连接池。

连接池:RealConnectionPool

RealConnectionPool内部有一个ConcurrentLinkedQueue<RealConnection类型的connections,用于持有所有连接。在创建OkHttpClient时,会创建默认的最大空闲连接数为5,存活时间为5分钟的连接池。

缓存策略:CacheInterceptor

缓存拦截器通常情况下只支持GET方法请求的缓存,每次请求都会先根据URL计算出key,然后在DiskLruCache中获取缓存快照(上次请求缓存的数据),假如有的话。然后根据缓存快照和请求报文,生成缓存策略,即根据请求报文和响应报文的首部行中相关字段(Cache-ControlEtag等等)来生成策略。根据不同的缓存策略进行不同的操作。

  1. 通过url的md5+hex获取缓存快照

    通过RequestURL计算出的md5hex值作为key,来获取DiskLruCache中的缓存快照SnapShotSnapshot缓存了请求报文和响应报文的相关数据,例如请求报文的请求行和响应报文的状态行。通过SnapShot构建Entry对象,该对象主要存储了请求报文和响应报文的首部信息。最后通过EntrySnapShot的创建出缓存响应Response

    SnapShot通过snapshot.getSource(ENTRY_METADATA)获取首部元数据信息,和snapshot.getSource(ENTRY_BODY)获取缓存的响应报文数据部分。

  2. CacheStrategy.Factory计算缓存策略

    通过 CacheStrategy.Factory(now, chain.request(), cacheCandidate).compute()生成的CacheStartegy对象含有两个属性networkRequestcacheResponse,当cacheResponse==null表示不使用缓存,从服务器拉取数据;当networkRequest==null表示强制使用缓存。同时为null,表示不满足only-if-cachedcompute函数主要是根据请求报文和响应报文的请求头来生成缓存策略。

    **cacheResponse==null**情况:

    • 本地没有缓存,即第一步得出的cacheCandidate==nll
    • HTTP中不支持缓存的报文或者请求报文和响应报文首部行设置了Cache-Control:no-store
    • 缓存的响应报文请求头都没设置ETag,Last-Modified,Date字段。

    **networkRequest==null**情况:

    • request设置了Cache-Control:only-if-cached
    • 使用协商缓存,且缓存未过期。
  3. 判断networkRequest==null的情况,表示只使用缓存。

  4. 发起网络请求,若服务器响应304且本地缓存不为null,则使用本地缓存,并更新本地缓存。

  5. 最后将请求报文和响应报文存放到缓存中,仅支持GET缓存

  override fun intercept(chain: Interceptor.Chain): Response {
    val call = chain.call()
    //第一步:通过url的md5+hex获取缓存快照
    val cacheCandidate = cache?.get(chain.request())

    val now = System.currentTimeMillis()
	//计算缓存策略
    val strategy = CacheStrategy.Factory(now, chain.request(), cacheCandidate).compute()
    val networkRequest = strategy.networkRequest
    val cacheResponse = strategy.cacheResponse

    cache?.trackResponse(strategy)
    val listener = (call as? RealCall)?.eventListener ?: EventListener.NONE

    if (cacheCandidate != null && cacheResponse == null) {
      // The cache candidate wasn't applicable. Close it.
      cacheCandidate.body?.closeQuietly()
    }

    //请求报文使用缓存,即请求头携带`Cache-Control:if-only-cached`
    if (networkRequest == null && cacheResponse == null) {
      return Response.Builder()
          .request(chain.request())
          .protocol(Protocol.HTTP_1_1)
          .code(HTTP_GATEWAY_TIMEOUT)
          .message("Unsatisfiable Request (only-if-cached)")
          .body(EMPTY_RESPONSE)
          .sentRequestAtMillis(-1L)
          .receivedResponseAtMillis(System.currentTimeMillis())
          .build().also {
            listener.satisfactionFailure(call, it)
          }
    }

    // networkRequest==null表示不使用网络请求
    if (networkRequest == null) {
      return cacheResponse!!.newBuilder()
          .cacheResponse(stripBody(cacheResponse))
          .build().also {
            listener.cacheHit(call, it)
          }
    }

    if (cacheResponse != null) {
      listener.cacheConditionalHit(call, cacheResponse)
    } else if (cache != null) {
      listener.cacheMiss(call)
    }

    var networkResponse: Response? = null
    try {
      	//发起网络请求,也就是会调用CallServerInterceptor的intercept函数
        networkResponse = chain.proceed(networkRequest)
    } finally {
      // If we're crashing on I/O or otherwise, don't leak the cache body.
      if (networkResponse == null && cacheCandidate != null) {
        cacheCandidate.body?.closeQuietly()
      }
    }

    //如果有本地缓存,且服务器返回304报文的,则使用响应报文
    if (cacheResponse != null) {
      if (networkResponse?.code == HTTP_NOT_MODIFIED) {
        val response = cacheResponse.newBuilder()
            .headers(combine(cacheResponse.headers, networkResponse.headers))
            .sentRequestAtMillis(networkResponse.sentRequestAtMillis)
            .receivedResponseAtMillis(networkResponse.receivedResponseAtMillis)
            .cacheResponse(stripBody(cacheResponse))
            .networkResponse(stripBody(networkResponse))
            .build()

        networkResponse.body!!.close()

        //更新缓存
        cache!!.trackConditionalCacheHit()
        cache.update(cacheResponse, response)
        return response.also {
          listener.cacheHit(call, it)
        }
      } else {
        cacheResponse.body?.closeQuietly()
      }
    }

    val response = networkResponse!!.newBuilder()
        .cacheResponse(stripBody(cacheResponse))
        .networkResponse(stripBody(networkResponse))
        .build()

    if (cache != null) {
      if (response.promisesBody() && CacheStrategy.isCacheable(response, networkRequest)) {
        //存放缓存
        val cacheRequest = cache.put(response)
        return cacheWritingResponse(cacheRequest, response).also {
          if (cacheResponse != null) {
            // This will log a conditional cache miss only.
            listener.cacheMiss(call)
          }
        }
      }
	  //仅支持GET缓存
      if (HttpMethod.invalidatesCache(networkRequest.method)) {
        try {
          cache.remove(networkRequest)
        } catch (_: IOException) {
          // The cache cannot be written.
        }
      }
    }

    return response
  }
复制代码

桥接模式:BridgeInterceptor

之所以将它称为桥接模式拦截器,是因为它将应用发起的请求转化成HTTP请求所需的内容,将网络响应数据转化成应用数据。其实也没那么神奇,就是已有的Request,判断请求报文是否添加一些头部信息,没有话就帮我们添加,如:Content-TypeContent-Length等等。

请求报文首部行:

  • Content-Type:如果在ReqeuestBody添加了ContentType,则帮我们添加到header
  • Content-Length:如果ReqeuestBodycontentLength没有设置,则添加Transfer-Encoding:chunked,否则添加到header
  • Transfer-Encoding:chunked,在没有ReqeuestBody情况下才会设置该请求头。
  • Host:域名
  • Connection:Keep-Alive
  • Accept-Encoding: gzip如果帮我们添加了该请求头,还要负责帮我们解压缩。
  • Cookie:XXX 假如有的话
  • User-Agent:okhttp/${OkHttp.VERSION}
 override fun intercept(chain: Interceptor.Chain): Response {
    val userRequest = chain.request()
    val requestBuilder = userRequest.newBuilder()

    val body = userRequest.body
    if (body != null) {
      val contentType = body.contentType()
      if (contentType != null) {
        requestBuilder.header("Content-Type", contentType.toString())
      }

      val contentLength = body.contentLength()
      if (contentLength != -1L) {
        requestBuilder.header("Content-Length", contentLength.toString())
        requestBuilder.removeHeader("Transfer-Encoding")
      } else {
        requestBuilder.header("Transfer-Encoding", "chunked")
        requestBuilder.removeHeader("Content-Length")
      }
    }
	//Host:域名 请求头
    if (userRequest.header("Host") == null) {
      requestBuilder.header("Host", userRequest.url.toHostHeader())
    }
	//Connection:Keep-Alive HTTP1.1 短连接请求头
    if (userRequest.header("Connection") == null) {
      requestBuilder.header("Connection", "Keep-Alive")
    }

    // If we add an "Accept-Encoding: gzip" header field we're responsible for also decompressing
    // the transfer stream.
    var transparentGzip = false
    if (userRequest.header("Accept-Encoding") == null && userRequest.header("Range") == null) {
      transparentGzip = true
      requestBuilder.header("Accept-Encoding", "gzip")
    }

    val cookies = cookieJar.loadForRequest(userRequest.url)
    if (cookies.isNotEmpty()) {
      requestBuilder.header("Cookie", cookieHeader(cookies))
    }

    if (userRequest.header("User-Agent") == null) {
      requestBuilder.header("User-Agent", userAgent)
    }

    val networkResponse = chain.proceed(requestBuilder.build())

    cookieJar.receiveHeaders(userRequest.url, networkResponse.headers)

    val responseBuilder = networkResponse.newBuilder()
        .request(userRequest)

    if (transparentGzip &&
        "gzip".equals(networkResponse.header("Content-Encoding"), ignoreCase = true) &&
        networkResponse.promisesBody()) {
      val responseBody = networkResponse.body
      if (responseBody != null) {
        val gzipSource = GzipSource(responseBody.source())
        val strippedHeaders = networkResponse.headers.newBuilder()
            .removeAll("Content-Encoding")
            .removeAll("Content-Length")
            .build()
        responseBuilder.headers(strippedHeaders)
        val contentType = networkResponse.header("Content-Type")
        responseBuilder.body(RealResponseBody(contentType, -1L, gzipSource.buffer()))
      }
    }

    return responseBuilder.build()
  }
复制代码

重试恢复:RetryAndFollowUpInterceptor

该拦截器在客户端允许重试恢复机制下,主要根据网络请求抛出的一些异常类型或者响应报文的状态码,进行重试恢复请求。如果该异常或者状态码不支持恢复,或者重试次数达到了设置次数,则抛出异常,本次客户端发起的请求。

  override fun intercept(chain: Interceptor.Chain): Response {
    val realChain = chain as RealInterceptorChain
    var request = chain.request
    val call = realChain.call
    var followUpCount = 0
    var priorResponse: Response? = null
    var newExchangeFinder = true
    var recoveredFailures = listOf<IOException>()
    while (true) {
      call.enterNetworkInterceptorExchange(request, newExchangeFinder)

      var response: Response
      var closeActiveExchange = true
      try {
        if (call.isCanceled()) {
          throw IOException("Canceled")
        }

        try {
          response = realChain.proceed(request)
          newExchangeFinder = true
        } catch (e: RouteException) {
          // The attempt to connect via a route failed. The request will not have been sent.
          if (!recover(e.lastConnectException, call, request, requestSendStarted = false)) {
            throw e.firstConnectException.withSuppressed(recoveredFailures)
          } else {
            recoveredFailures += e.firstConnectException
          }
          newExchangeFinder = false
          continue
        } catch (e: IOException) {
          // An attempt to communicate with a server failed. The request may have been sent.
          if (!recover(e, call, request, requestSendStarted = e !is ConnectionShutdownException)) {
            throw e.withSuppressed(recoveredFailures)
          } else {
            recoveredFailures += e
          }
          newExchangeFinder = false
          continue
        }

        //while是一个死循环
        if (priorResponse != null) {
          response = response.newBuilder()
              .priorResponse(priorResponse.newBuilder()
                  .body(null)
                  .build())
              .build()
        }

        val exchange = call.interceptorScopedExchange
        //判读一些常见的网络错误或者重定向,例如400,然后尝试新建request的恢复连接
        val followUp = followUpRequest(response, exchange)

        if (followUp == null) {
          if (exchange != null && exchange.isDuplex) {
            call.timeoutEarlyExit()
          }
          closeActiveExchange = false
          return response
        }

        val followUpBody = followUp.body
        if (followUpBody != null && followUpBody.isOneShot()) {
          closeActiveExchange = false
          return response
        }

        response.body?.closeQuietly()

        if (++followUpCount > MAX_FOLLOW_UPS) {
          throw ProtocolException("Too many follow-up requests: $followUpCount")
        }

        request = followUp
        priorResponse = response
      } finally {
        call.exitNetworkInterceptorExchange(closeActiveExchange)
      }
    }
  }
复制代码

recover函数主要检测发生的异常是否属于可以恢复的类型。如果设置了client.retryOnConnectionFailure=false,直接抛出异常不会重新进行请求。主要是根据一些错误的类型,来判断该错误是否避免,如果不能避免就直接抛异常,可以的话重新进入下次while循环。

自定义拦截器

我们自定的拦截器有两种,一种是普通的应用拦截器,也就是拦截链最开始的地方。第二种是网络拦截器,在拦截链倒数第二,即发起网络前。前者处于拦截链的前端,可以多次调用拦截链后续的拦截器,但拦截不到它们处理的内容。后者只有发起网络才会被拦截到,例如命中缓存的话,并不会调用到。因此在自定义拦截器时,要根据具体的需求实现不同拦截器。

责任链模式

OkHttp的拦截链使用了责任链设计模式,将一个请求交给多个对象处理,解耦了请求的发送者和接收者。将对象构成链,并将请求沿着该链传递,直到某个处理对象终止该请求。例如缓存拦截器命中缓存后终止将请求交付给下个一个处理对象。

每个处理对象根据自己的特性,即处理能力,当请求满足自身条件,则进行处理而不继续传递。

总结

通过分析OkHttp的源码,发现大部分的HTTP知识点,也就是OkHttp自己实现了一套从低到上的网络请求框架。以前总以为OkHttp应该很复杂,毕竟那么流行。却没想到如此的基础和稳定,学习了,不要惧怕源码,勇敢过去学。


【相关连接】

HTTP与HTTPS

运输层TCP

OkHttp使用

欢迎点赞+关注+评论三连击

Github】【掘金】【博客

分类:
Android
标签:
收藏成功!
已添加到「」, 点击更改
