在上一篇文章中,我们通过AST完成了微信小程序组件的多端编译,在这篇文章中,让我们更深入一点,通过AST完成一个javascript元循环求值器
结构
一个元循环求值器,完整的应该包含以下内容:
- tokenizer:对代码文本进行词法和语法分析,将代码分割成若干个token
- parser:根据token,生成AST树
- evaluate:根据AST树节点的type,执行对应的apply方法
- apply:根据环境,执行实际的求值计算
- scope:当前代码执行的环境
代码目录
根据结构看,我将代码目录大致拆分为以下几个文件
- parser
- eval
- scope
tokenizer和parser这两个过程不是本文的重点,我统一放在了parser中,交由 @babel/parser
来处理。
evaluate和apply这两个过程我统一放在了eval文件中处理,一会我们重点看下这部分。
scope则放入scope文件。
evaluate-apply
这其实是一个递归计算的过程。
首先,evaluate
接收两个参数,node
当前遍历的AST树节点和 scope
当前环境。然后,evaluate去根据 node
的 type
属性,判断该节点是什么类型。判断出类型后,执行 apply
去求值这个节点所代表的表达式。apply
中会再次递归的执行 evaluate
去计算当前节点的子节点。最终,执行完整颗AST树。
evaluate
的具体实现如下
const evaluate = (node: t.Node, scope) => {
const evalFunc = evaluateMap[node.type];
if (!evalFunc) {
throw `${node.loc} ${node.type} 还未实现`;
}
return evalFunc(node, scope);
}
其中,evaluateMap
是所有实现的节点类型集合。
根据 @babel/types
,我们可以把节点类型分为以下这么几类:File、Program、Identifier(标识符)、Literal(字面量)、Statement(语句)、Expression(表达式)
File、Program
这两类是遍历的起点,代码如下
File(node: t.File, scope) {
evaluate(node.program, scope);
},
Program(node: t.Program, scope) {
for (const n of node.body) {
evaluate(n, scope);
}
},
Identifier
标识符。当遍历到这类节点时,需要从环境中取值,例如
var a = 'hello';
console.log(a); // 这个a对应的ast树节点类型就是Identifier类型
具体实现如下:
Identifier(node: t.Identifier, scope) {
const $var = scope.$find(node.name);
if (!$var) {
throw `[Error] ${node.loc}, '${node.name}' 未定义`;
}
return $var.$get();
},
Literal
字面量。当遍历到这类节点时,直接返回值即可。代码如下
StringLiteral(node: t.StringLiteral, scope) {
return node.value;
},
NumericLiteral(node: t.NumericLiteral, scope) {
return node.value;
},
BooleanLiteral(node: t.BooleanLiteral, scope) {
return node.value;
},
NullLiteral(node: t.NullLiteral, scope) {
return null;
},
Declaration
声明。当遍历到这类节点时,需要在scope中完成声明。声明分为两类,函数声明和变量声明。代码如下
FunctionDeclaration(node: t.FunctionDeclaration, scope) {
const func = evaluateMap.FunctionExpression(node, scope);
scope.$var(node.id.name, func);
},
VariableDeclaration(node: t.VariableDeclaration, scope) {
const { kind, declarations } = node;
for (const decl of declarations) {
const varName =decl.id.name;
const value = decl.init ? evaluate(decl.init, scope) : void 0;
if (!scope.$define(kind, varName, value)) {
throw `[Error] ${name} 重复定义`
}
}
},
Statement
语句。当遍历到这类节点时,就要根据环境去执行语句了。这边会递归调用evaluate来计算语句中的每一部分。以If语句为例
IfStatement(node: t.IfStatement, scope) {
if (evaluate(node.test, scope)) {
return evaluate(node.consequent, scope);
}
if (node.alternate) {
const ifScope = new Scope('block', scope, true);
return evaluate(node.alternate, ifScope)
}
},
Expression
表达式。当遍历到这类节点时,跟Statement类似,需要去递归计算每一部分,然后执行对应的表达式。以逻辑运算表达式为例
LogicalExpression(node: t.LogicalExpression, scope) {
const { left, right, operator } = node;
const expressionMap = {
'&&': () => evaluate(left, scope) && evaluate(right, scope),
'||': () => evaluate(left, scope) || evaluate(right, scope),
}
return expressionMap[operator]();
},
以上就是 evaluate-apply
的大致过程。
完整代码可以在仓库中查看。Nvwa.js
scope
我们再来看下 scope
该如何实现。
class Scope implements IScope {
public readonly variables: EmptyObj = Object.create(null);
constructor(
private readonly scopeType: ScopeType,
private parent: Scope = null,
public readonly shared = false,
) { }
}
我们构造一个类来模拟 scope
。可以看到,Scope
类包含了以下4个属性:
- variables:当前环境下存在的变量
- scopeType:当前环境的type
- parent:当前环境的父环境
- shared:有些时候不需要重复构造子环境,故用此标识
接下来我们看下该如何在环境中声明变量
首先构造一个类来模拟变量
class Variable implements IVariable {
constructor(
private kind: Kind,
private value: any
){ }
$get() {
return this.value
}
$set(value: any) {
if (this.kind === 'const') {
return false
}
this.value = value;
return true;
}
}
这个类中有两个属性和两个方法
kind
用于标识该变量是通过var
、let
还是const
声明value
表示该变量的值$get
和$set
分别用于获取和设置该变量的值
有了 Variable
类之后,我们就可以编写 Scope
类中的声明变量的方法了。
let
和 const
的声明方式基本一样
$const(varName: string, value: any) {
const variable = this.variables[varName];
if (!variable) {
this.variables[varName] = new Variable('const', value);
return true;
}
return false;
}
$let(varName: string, value: any) {
const variable = this.variables[varName];
if (!variable) {
this.variables[varName] = new Variable('let', value);
return true;
}
return false;
}
var
的声明方式稍微有一点差异,因为js中,除了在 function
中,用var
声明的变量是会被声明到父级作用域的(js的历史遗留坑)。我们看下代码
$var(varName: string, value: any) {
let scope: Scope = this;
while (!!scope.parent && scope.scopeType !== 'function') {
scope = scope.parent;
}
const variable = scope.variables[varName];
if (!variable) {
scope.variables[varName] = new Variable('var', value);
} else {
scope.variables[varName] = variable.$set(value);
}
return true
}
除了声明,我们还需要一个寻找变量的方法,该方法会从当前环境开始,一直沿着作用域链,找到最外层的环境为止。因此,代码实现如下
$find(varName: string): null | IVariable {
if (Reflect.has(this.variables, varName)) {
return Reflect.get(this.variables, varName);
}
if (this.parent) {
return this.parent.$find(varName);
}
return null;
}
以上,一个基本的javascript元循环求值器就完成了
最后
大家可以在 codesandbox 在线体验一下。
完整的项目地址是:nvwajs,欢迎鞭策,欢迎star。
