介绍

按照官网的说法,Redis位图Bitmaps不是实际的数据类型,而是在字符串类型上定义的一组面向位的操作。在Redis中字符串限制最大为512MB,所以位图中最大可以设置2^32个不同的位(42.9亿个)。图位的最小单位是比特(bit),每个bit的值只能是0或1。

位图的存储大小计算: (maxOffset / 8 / 1024 / 1024)MB。其中maxOffset为位图的最大位数

基本用法

SETBIT key offset value

设置指定key的值在offset处的bit值,offset从0开始。返回值为在offset处原来的bit值

# 通过位操作将 h 改成 i
127.0.0.1:6379> SET h h         # 二进制为 01101000
OK
127.0.0.1:6379> SETBIT h 7 1    # 将最后一位改成1 => 01101001
(integer) 0
127.0.0.1:6379> GET h
"i"

GETBIT key offset

获取指定key的值在offset处的bit值,offset从0开始。如果offset超出了当前位图的范围,则返回0。

127.0.0.1:6379set i i       # 二进制为 01101001
OK
127.0.0.1:6379getbit i 0    # 第1位为0
(integer) 0
127.0.0.1:6379getbit i 1    # 第2位为0
(integer) 1
127.0.0.1:6379getbit i 7    # 第8位为0
(integer) 1

BITCOUNT key [start end]

统计指定key值中被设置为1的bit数。可以通过指定参数star和end来限制统计范围。

注意,这里的star和end不是指bit的下标,而是字节(byte)的下标。比如start为1,则实际对应的bit下标为8(1byte = 8 bit)

127.0.0.1:6379set hi hi           # 二进制为 0110100001101001
OK
127.0.0.1:6379bitcount hi         # 所有是1的位数:7个
(integer) 7
127.0.0.1:6379bitcount hi 1 2     # 即统计 01101001 中1的位数
(integer) 4

BITPOS key bit [start] [end]

统计首次出现的0或1的bit位,可以通过start和end来指定范围,同样是指字节的下标。

  • 在不存在的key或者空字符串中查找1,则返回-1
  • 在所有bit都为1中查找bit为0的情况下,返回字符串最右边的第一个空位
    127.0.0.1:6379get nilkey           # 不存在的key
    (nil)
    127.0.0.1:6379bitpos nilkey 1      # 在不存在的key中查首次出现1的位
    (integer-1
    127.0.0.1:6379setbit nilkey 0 0    # 空字符串
    (integer) 0
    127.0.0.1:6379get nilkey
    "\x00"
    127.0.0.1:6379bitpos nilkey 1
    (integer-1

BITOP operation destkey key [key …]

对一个或多个二进制位字符串进行操作,并将结果保存到 destkey 上。当某个字符串长度不够时,对应的位用0补上

  • AND(逻辑与):都为1返回1,否则返回0
    127.0.0.1:6379set a a                  # 二进制  01100001
    OK
    127.0.0.1:6379set c c                  # 二进制  01100011
    OK
    127.0.0.1:6379bitop and destkey a c    # 与操作  01100001 -a
    (integer) 1
    127.0.0.1:6379get destkey
    "a"
  • OR(逻辑或):只要有一个1就返回1,否则返回0
    127.0.0.1:6379set a a                 # 二进制  01100001
    OK
    127.0.0.1:6379set b b                 # 二进制  01100010
    OK
    127.0.0.1:6379bitop or destkey a b    # 或操作  01100011 -c
    (integer) 1
    127.0.0.1:6379get destkey
    "c"
    127.0.0.1:6379>
  • XOR(逻辑异或):当都是0或者都是1时返回0,否则返回1
    127.0.0.1:6379set a a                 # 二进制  01100001
    OK
    127.0.0.1:6379set z Z                 # 二进制  01011010 (大写的Z)
    OK
    127.0.0.1:6379bitop xor destkey a z   # 异或    00111011 -> ; 分号
    (integer) 1
    127.0.0.1:6379get destkey
    ";"
  • NOT(逻辑非):取反,1变成0,0变成1。只能传入一个要操作的key
    01010101 -> 10101010

场景实战

这里用一个用户签到的例子来讲解如何在实战中应用,需求:

  • 实现用户签到
  • 统计今天所有的签到数量
  • 获取指定用户全年的签到数
  • 统计近7天连续签到的用户数量
  • 统计本月全部签到过的用户数量
  • 统计近7天有过签到的用户数量

使用位图的好处:

  • 最直观的一点占用存储少,1个人1年的数据也就365 bit,46个字节;
  • 通过位运算操作多个字符串,效率高
  • 当别人还在用数据库记录签到信息的时候,你用位图操作,逼格一下就上去了;

这里基于SpringBoot进行演示:

  • 每天的签到情况作为一条记录,key格式为sign:{yyyyMMdd}
  • 用户ID作为偏移量

用户签到

将用户ID作为偏移量,通过setBit设置该位置的值为1

查询用户今天是否已经签到了

将用户ID作为偏移量,通过getBit查询该位置上的值是否为1

统计今天所有的签到数量

通过bitCount去实现统计

统计指定用户全年的签到数

Redis中并没有提供对多个二进制位字符串进行求和操作,我们需要自己去统计。思路:

  • 获取本年所有签到记录的key列表,即sign:2020开头的key,可以通过Redis指令keys sign:2020*获取
  • 遍历获取到的key列表,统计已经签到过的key的数量

统计近7天连续签到的用户数量

  • 对近7天的签到记录的进行逻辑与操作,生成一个连续七天签到的记录
  • 对生成的记录进行bitCount

统计近7天有过签到的用户数量

和统计7天连续签到思路一样,只是这里使用逻辑或操作

完整代码

Service

@Service
public class RedisService {

    private final StringRedisTemplate stringRedisTemplate;

    public RedisService(StringRedisTemplate stringRedisTemplate) {
        this.stringRedisTemplate = stringRedisTemplate;
    }

    /**
     * 获取指定格式的key
     *
     * @param pattern 格式
     * @return set
     */

    public Set<String> getKeys(String pattern) {
        return stringRedisTemplate.keys(pattern);
    }

    /**
     * 设置指定位的值
     *
     * @param key    键
     * @param offset 偏移量 0开始 对应bit的位置
     * @param value  true为1,false为0
     * @return boolean
     */

    public Boolean setBit(String key, long offset, boolean value) {
        return stringRedisTemplate.opsForValue().setBit(key, offset, value);
    }

    /**
     * 获取指定位的值
     *
     * @param key    键
     * @param offset 偏移量 0开始
     * @return boolean
     */

    public Boolean getBit(String key, long offset) {
        return stringRedisTemplate.opsForValue().getBit(key, offset);
    }

    /**
     * 统计字符串被设置为1的bit数
     *
     * @param key 键
     * @return long
     */

    public Long bitCount(String key) {
        return stringRedisTemplate.execute(
                (RedisCallback<Long>) connection -> connection.bitCount(key.getBytes())
        );
    }

    /**
     * 统计字符串指定位上被设置为1的bit数
     *
     * @param key   键
     * @param start 开始位置  注意对应byte的位置,是bit位置*8
     * @param end   结束位置
     * @return long
     */

    public Long bitCount(String key, long start, long end) {
        return stringRedisTemplate.execute(
                (RedisCallback<Long>) connection -> connection.bitCount(key.getBytes(), start, end)
        );
    }

    /**
     * 不同字符串之间进行位操作
     *
     * @param op      操作类型:与、或、异或、否
     * @param destKey 最终存放结构的键
     * @param keys    要操作的键
     * @return Long
     */

    public Long bitOp(RedisStringCommands.BitOperation op, String destKey, Collection<String> keys) {
        int size = keys.size();
        byte[][] bytes = new byte[size][];

        int index = 0;
        for (String key : keys) {
            bytes[index++] = key.getBytes();
        }
        return stringRedisTemplate.execute((RedisCallback<Long>) con -> con.bitOp(op, destKey.getBytes(), bytes));
    }

    /**
     * 对符合指定格式的key值进行未操作
     *
     * @param op      操作类型:与、或、异或、否
     * @param destKey 存放结果的键
     * @param pattern key格式
     * @return Long
     */

    public Long bitOp(RedisStringCommands.BitOperation op, String destKey, String pattern) {
        Set<String> keys = getKeys(pattern);
        int size = keys.size();
        if (size == 0) {
            return 0L;
        }
        byte[][] bytes = new byte[size][];

        int index = 0;
        for (String key : keys) {
            bytes[index++] = key.getBytes();
        }
        return stringRedisTemplate.execute((RedisCallback<Long>) con -> con.bitOp(op, destKey.getBytes(), bytes));
    }
}

controller

@RestController
@RequestMapping("/redis/bit")
public class BitMapController {

    private final DateTimeFormatter formatters = DateTimeFormatter.ofPattern("yyyyMMdd");

    /**
     * 定义签到前缀
     * key格式为 sing:{yyyyMMdd}
     */

    private static final String SIGN_PREFIX = "sign:";

    /**
     * 连续一周签到
     */

    private static final String SIGN_ALL_WEEK_KEY = "signAllWeek";

    /**
     * 连续一个月签到
     */

    private static final String SIGN_ALL_MONTH_KEY = "signAllMonth";

    /**
     * 一周内有签到过的
     */

    private static final String SIGN_IN_WEEK_KEY = "signInWeek";

    private final RedisService redisService;

    public BitMapController(RedisService redisService) {
        this.redisService = redisService;
    }

    /**
     * 初始化本年今天之前的测试数据
     */

    @GetMapping("/init")
    public void initData() {
        // 获取本年的日期列表
        List<String> dateKeyList = new ArrayList<>();
        LocalDate curDate = LocalDate.now();
        LocalDate beginDate = LocalDate.parse("2020-01-01");
        while (beginDate.isBefore(curDate)) {
            dateKeyList.add(SIGN_PREFIX + beginDate.format(formatters));
            beginDate = beginDate.plusDays(1);
        }
        // 是否签到
        boolean isSign;
        StringBuilder signInfo;
        for (int i = 1; i < 6; i++) {
            signInfo = new StringBuilder("用户【").append(i).append("】:");
            for (String dateKey : dateKeyList) {
                if (i == 1) {
                    // 用户1全部签到
                    isSign = true;
                } else {
                    // 其他用户随机
                    isSign = Math.random() > 0.5;
                }
                redisService.setBit(dateKey, i, isSign);
                signInfo.append(isSign ? 1 : 0).append(", ");
            }
            System.out.println(signInfo.toString());
        }
    }

    /**
     * 用户当天签到
     * 用户ID作为位图的偏移量
     */

    @GetMapping("/sign/{userId}")
    public String sign(@PathVariable Long userId) {
        redisService.setBit(SIGN_PREFIX + getCurDate(), userId, true);
        return "签到成功";
    }

    /**
     * 查询用户今天是否已经签到了
     */

    @GetMapping("/isSign/{userId}")
    public String isSign(@PathVariable Long userId) {
        Boolean isSign = redisService.getBit(SIGN_PREFIX + getCurDate(), userId);
        if (isSign) {
            return String.format("用户【%d】今日已签到", userId);
        }
        return String.format("用户【%d】今日尚未签到,请签到", userId);
    }

    /**
     * 统计今天所有的签到数量
     */

    @GetMapping("/todayCount")
    public String todayCount() {
        return String.format("今日已签到人数: %d", redisService.bitCount(SIGN_PREFIX + getCurDate()));
    }

    /**
     * 统计指定用户全年的签到数
     */

    @GetMapping("/userYearSign/{userId}")
    public String userYearSign(@PathVariable Long userId) {
        int year = LocalDate.now().getYear();
        // 获取所有的key
        Set<String> keys = redisService.getKeys(SIGN_PREFIX + year + "*");
        /*
         * 可以使用BitSet 去存储用户每天的签到信息,用于其他的操作
         * BitSet users = new BitSet();
         * 统计所有已经签到的数量 对应 redis的bitCount
         * users.cardinality()
         */

        int signCount = 0;
        for (String key : keys) {
            if (redisService.getBit(key, userId)) {
                signCount++;
            }
        }
        return String.format("本年已累计签到: %d 次", signCount);
    }

    /**
     * 统计近7天连续签到的用户数量
     * 逻辑与
     */

    @GetMapping("/signAllWeek")
    public String signAllWeek() {
        List<String> weekDays = getWeekKeys();
        redisService.bitOp(RedisStringCommands.BitOperation.AND, SIGN_ALL_WEEK_KEY, weekDays);
        return String.format("近7天连续签到用户数:%d", redisService.bitCount(SIGN_ALL_WEEK_KEY));
    }

    /**
     * 统计本月全部签到过的用户数量
     */

    @GetMapping("/signAllMonth")
    public String signAllMonth() {
        redisService.bitOp(
                RedisStringCommands.BitOperation.AND,
                SIGN_ALL_MONTH_KEY,
                SIGN_PREFIX + LocalDate.now().getYear()
        );
        return String.format("月全部签到过的用户数:%d", redisService.bitCount(SIGN_ALL_MONTH_KEY));
    }

    /**
     * 统计近7天有过签到的用户数量,只签到1次也算
     * 逻辑或
     */

    @GetMapping("/signInWeek")
    public String signInWeek() {
        List<String> weekDays = getWeekKeys();
        redisService.bitOp(RedisStringCommands.BitOperation.OR, SIGN_IN_WEEK_KEY, weekDays);
        return String.format("近7天有过签到的用户数:%d", redisService.bitCount(SIGN_IN_WEEK_KEY));
    }

    /**
     * 获取当天的日期
     *
     * @return yyyyMMdd
     */

    private String getCurDate() {
        return LocalDate.now().format(formatters);
    }

    /**
     * 获取近一周的日期对应的key
     */

    private List<String> getWeekKeys() {
        List<String> dateList = new ArrayList<>();
        LocalDate curDate = LocalDate.now();
        dateList.add(SIGN_PREFIX + curDate.format(formatters));
        for (int i = 1; i < 7; i++) {
            dateList.add(SIGN_PREFIX + curDate.plusDays(-i).format(formatters));
        }
        return dateList;
    }
}

补充

  • 上述例子中我们默认用户ID是数字类型,如果你们的用户ID是字符串的,那么可以将用户ID作为key,取当天是今年的第几天作为偏移量,这样一天记录就是一个人全年的签到记录;
  • 在进行BITOP操作时会重新生成一个结果的key,可以在每天凌晨通过定时任务去统计之前的记录来生成这个结果key,这样在业务中就可以直接通过这个结果key来统计数据

访问源码

所有代码均上传至Github上,方便大家访问

>>>>>> Redis实战 — 位图 <<<<<<
