自定义Vue组件 - EasyToast

鱼汤侠
357 阅读7分钟

如何使用Vue自定义组件？如何使用Vue动画？接下来讲为各位看官进行解答，通过封装一个简单的吐司组件，来贯穿讲解整个组件的构建。

初始化

  1. 创建EasyToast.vue文件
<template>
  <div class="easy-toast">
    <span>我是吐司</span>
  </div>
</template>
<script>
export default {
  name: 'EasyToast',
  props: {
  },
  mounted(){
  },
  methods: {
  }
}
</script>
  1. 在需要使用Toast组件的地方进行引入
<template>
  <div id="app">
    <EasyToast />
  </div>
</template>
<script>
import EasyToast from './EasyToast';
export default {
  name: 'app',
  components:{
    EasyToast
  },
  data(){
    return {
    }
  }
}

配置

  1. 对于Toast，参数基本有三种，其中包括提示文案、动画持续时间(下文讲解动画)、图标(成功、失败或者自定义图标)，我们将通过Props方式传递到组件内部，首先定义组件内接收配置的属性，如下
  ...
  name: 'EasyToast',
  props: {
    // 标题
    title: {
      type: String,
      default: '我是标题'
    },
    // 动画持续时间
    duration: {
      type: Number,
      default: 3000
    },
    // 吐司模式
    mode: {
      type: String,
      default: 'normal',
      validator: function(value){
        return ['normal','error','success'].indexOf(value) > -1
      }
    }
  }
  ...

参数尽量要配置类型及默认值，如果是特殊参数，例如枚举，Vue并没有提供响应的类型配置，我们可以使用validator进行自定义验证。

  1. 传递参数 (为节约篇幅，我们将简化代码，结合上一章节查看)
<template>
    ...
    <EasyToast :title="title" />
    ...
</template>
<script>
export default {
  name: 'app',
  ...
  data(){
    return {
       title: "提交成功"
    }
  }
}
</script>

样式

上一章节我们已经把基本参数进行了配置，目前的Toast还只是简单的一个文本显示，并且是可见的，下面我们对其进行一个样式配置。因为是组件，基于低耦合、高内聚的原则，通过scoped属性实现样式的模块化，仅作用于当前组件，防止造成全局污染。EasyToast.vue内增加样式代码如下:

<script>
...
</script>
<style lang="scss" scoped>
.easy-toast{
  width: 140px;
  background-color: #000000;
  position: fixed;
  top: 50%;
  left: 50%;
  transform: translate(-50%,-50%);
  text-align: center;
  padding: 20px 10px;
  border-radius: 5px;
  display: flex;
  flex-direction: column;
  align-items: center;

  &__title{
    color: white;
    font-size: 16px;
    line-height: 22px;
  }
  &__icon{
    width: 32px;
    height: 32px;
    display: inline-block;
    margin-bottom: 12px;
    background-size: contain;
    background-position: center;

    &--error{
    }
    &--success{
    }
  }
}
</style>

默认效果

成功

失败

显示和隐藏

目前为止，样式已经补充上了，接下来便需要进行显示和隐藏的控制。一般来讲，显示和隐藏需要由使用者来控制，而实现控制的方式有多种。

Toast采用v-model来进行控制显隐，可能并不是最优的方案，主要目的是学习一下v-model的一些特殊用法。 v-model我们通常会在input标签中使用，进行双向数据绑定，使用它的优势在与通过双向数据绑定，能够同步组件内和外部使用者的状态。

实际上，v-model等价与v-bind:value属性，所以我们在组件内部增加一个value属性(Boolean类型，默认false)，来接收绑定的数据，代码如下: EasyToast.vue

  name: 'EasyToast',
  props: {
    ...
    // 吐司模式
    mode: {
      type: String,
      default: 'normal',
      validator: function(value){
        return ['normal','error','success'].indexOf(value) > -1
      }
    },
    value: {
      type: Boolean,
      default: false
    }
  }

上一章节，我们制作好了Toast样式，但是是用户可见的, 实际上默认应该是不可见状态，我们通过增加一个修饰类class隐藏，并通过value属性来控制easy-toast--hide是否使用，代码如下: EasyToast.vue

<template>
  <div :class="['easy-toast', value === false && 'easy-toast--hide']">
    ...
  </div>
</template>
<style lang="scss" scoped>
.easy-toast{
    ...
    &--hide{
        display:none;
    }
}
</style>

调用者通过v-model来进行显示的控制，代码如下

<template>
  <div id="app">
    <EasyToast
      v-model="toastShow"
      :title="title"
    />
  </div>
</template>
<script>
export default {
  name: 'app',
  ...
  data(){
    return {
      toastShow: flase,
      title: "提交成功",
    }
  }

}

对于Toast，一般是自动隐藏的，我们就需要在显示状态且duration时间结束后使其隐藏，可以通过监听value属性来增加控制隐藏的方法，代码如下: EasyToast.vue

<script>
export default {
  name: 'EasyToast',
  props: {
    ...
    value: {
      type: Boolean,
      default: false
    }
  },
  watch: {
    value(){
      if(this.value === true){
        // Toast显示时
        this.startTimer();
      } else {
        this.stopTimer();
      }
    }
  },
  // 组件销毁后，停止计时
  destroyed(){
    this.stopTimer();
  },
  methods: {
    // 停止计时
    stopTimer(){
      this.timer && clearTimeout(this.timer);
      this.timer = null;
    },
    // 开始计时
    startTimer(){
      this.stopTimer();
      this.timer = setTimeout(()=>{
        this.hide();
        this.stopTimer();
      }, this.duration);
    },
    // 隐藏
    hide(){
      this.$emit('input', false); // 正常Props不可以修改 通过emit “input”事件，来修改父组件状态，实现双向绑定
    }
  }
}
</script>

动画

上一章节，实现了显示和隐藏功能，但是太过单调，我们需要增加一些动画效果，使用Vue的transitions来实现，并配合css3动画，不再使用控制easy-toast--hide的方式，话不多说，直接上代码: EasyToast.vue

<template>
  <transition name="easy-toast-scale">
    <div v-show="value" class="easy-toast">
       ...
    </div>
  </transition>
</template>
<script>
...
</script>
<style lang="scss" scoped>
.easy-toast{
  ...
  transform: translate(-50%,-50%) scale(1);
  ...
}
.easy-toast-scale-enter-active, .easy-toast-scale-leave-active {
  transition: transform .3s;
}
.easy-toast-scale-enter, .easy-toast-scale-leave-to{
  transform: translate(-50%,-50%) scale(0);
}
</style>

完整代码 EasyToast.vue

<template>
  <transition name="easy-toast-scale">
    <div v-show="value" class="easy-toast">
      <i v-if="mode === 'success'" class="easy-toast__icon easy-toast__icon--success"></i>
      <i v-if="mode === 'error'" class="easy-toast__icon easy-toast__icon--error"></i>
      <span class="easy-toast__title">{{title}}</span>
    </div>
  </transition>
</template>
<script>
export default {
  name: 'EasyToast',
  props: {
    // 标题
    title: {
      type: String,
      default: '我是标题'
    },
    // 动画持续时间
    duration: {
      type: Number,
      default: 3000
    },
    // 吐司类型
    mode: {
      type: String,
      default: 'normal',
      validator: function(value){
        return ['normal','error','success'].indexOf(value) > -1
      }
    },
    value: {
      type: Boolean,
      default: false
    }
  },
  watch: {
    value(){
      if(this.value === true){
        // Toast显示时
        this.startTimer();
      } else {
        this.stopTimer();
      }
    }
  },
  // 组件销毁后，停止计时
  destroyed(){
    this.stopTimer();
  },
  methods: {
    // 停止计时
    stopTimer(){
      this.timer && clearTimeout(this.timer);
      this.timer = null;
    },
    // 开始计时
    startTimer(){
      this.stopTimer();
      this.timer = setTimeout(()=>{
        this.hide();
        this.stopTimer();
      }, this.duration);
    },
    // 隐藏
    hide(){
      this.$emit('input', false); // 正常Props不可以修改 通过emit “input”事件，来修改父组件状态，实现双向绑定
    }
  }
}
</script>
<style lang="scss" scoped>
.easy-toast{
  width: 140px;
  background-color: #000000;
  position: fixed;
  top: 50%;
  left: 50%;
  transform: translate(-50%,-50%) scale(1);
  text-align: center;
  padding: 20px 10px;
  border-radius: 5px;
  display: flex;
  flex-direction: column;
  align-items: center;

  &__title{
    color: white;
    font-size: 16px;
    line-height: 22px;
  }
  &__icon{
    width: 32px;
    height: 32px;
    display: inline-block;
    margin-bottom: 12px;
    background-size: contain;
    background-position: center;

    &--error{
    }
    &--success{
    }
  }
}
.easy-toast-scale-enter-active, .easy-toast-scale-leave-active {
  transition: transform .3s;
}
.easy-toast-scale-enter, .easy-toast-scale-leave-to{
  transform: translate(-50%,-50%) scale(0);
}
</style>

最终效果
