可能是最强大的RecyclerView框架
GitHub |
使用文档 | 备用访问
本框架在不影响RecyclerView的任何函数组件使用基础上开发. 本项目也将一直保持维护状态
欢迎贡献代码/问题
- 优雅的函数设计
- 详细的使用文档
- 简单的示例代码
- 高内聚低耦合
- 刷新不闪屏
- 双向数据绑定(DataBinding)
功能
- 多类型
- 单一数据模型一对多
- 多数据模型
- 添加头布局和脚布局
- 点击(防抖动)/长按事件
- 分组(展开折叠/递归层次/展开置顶/单一展开模式)
- 悬停
- 分割线/均布间隔(支持官方全部的
LayoutManager
) - 切换模式
- 选择模式(多选/单选/全选/取消全选/反选)
- 拖拽位置
- 侧滑删除
- 下拉刷新 | 上拉加载, 扩展SmartRefreshLayout即兼容其所有功能
- 预拉取索引(UpFetch) | 预加载索引(Preload)
- 缺省页
- 自动分页加载
- 扩展伸缩布局 (FlexboxLayoutManager)
- 扩展自动化网络请求 (Net), 该网络请求基于协程实现自动化的并发网络请求
安装
在项目根目录的 build.gradle 添加仓库
allprojects {
repositories {
// ...
maven { url 'https://jitpack.io' }
}
}
在 module 的 build.gradle 添加依赖
android {
//... 即使你不使用DataBinding也要打开其开关
buildFeatures.dataBinding = true
}
dependencies {
//...
implementation 'com.github.liangjingkanji:BRV:1.3.24'
}
License
Licensed under the Apache License, Version 2.0 (the "License");
you may not use this file except in compliance with the License.
You may obtain a copy of the License at
http://www.apache.org/licenses/LICENSE-2.0
Unless required by applicable law or agreed to in writing, software
distributed under the License is distributed on an "AS IS" BASIS,
WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
See the License for the specific language governing permissions and
limitations under the License.
预览
首页

功能界面
初始化
class MyApplication : Application() {
override fun onCreate() {
super.onCreate()
BindingAdapter.modelId = BR.m // 推荐在Application中进行初始化或使用之前即可
}
}
多类型
不同数据模型
rv.linear().setup {
addType<Model>(R.layout.item_1)
addType<Store>(R.layout.item_2)
}.models = data
一对多数据模型
开发中常常遇到一个列表, 列表每个数据对应的一个字段来判断itemType
addType<Model>{
// 使用年龄来作为判断返回不同的布局
when (age) {
23 -> {
R.layout.item_1
}
else -> {
R.layout.item_2
}
}
}
分割线
快速实现分割线
fun RecyclerView.divider(
@DrawableRes drawable: Int,
@RecyclerView.Orientation orientation: Int = RecyclerView.VERTICAL,
block: ((Rect, View, RecyclerView, RecyclerView.State) -> Boolean)? = null
)
监听事件
监听事件需要先添加想要监听的view
fun addClickable(@IdRes vararg id: Int)
// 过滤500毫秒内重复点击
fun addFastClickable(@IdRes vararg id: Int)
// 区别于上面函数不过滤重复点击事件
fun addLongClickable(@IdRes vararg id: Int)
// 长按事件
事件回调
onClick{
}
// 点击事件
onLongClick{
}
// 长按点击事件
onBind {
false
}
onBind
属于onBindViewHolder
事件监听.
如果你需要自己去设置数据或绑定事件就使用该函数. 返回值决定是否用框架内部默认的Databinding绑定布局. false
表示不绑定.
更简单的写法示例
rv.linear().setup {
addType<Model>{
R.layout.item_1
}
onClick(R.id.item, R.id.user_portrait){
}
onLongClick(R.id.item){
}
}.models = data
头布局/脚布局
头布局和脚布局在rv中算作一个item, 所以计算position
的时候应当考虑其中.
操作头布局
fun addHeader(view: View)
fun removeHeader(view: View)
fun clearHeader()
fun isHeader(@IntRange(from = 0) position: Int): Boolean
操作脚布局
fun addFooter(view: View)
fun removeFooter(view: View)
fun clearFooter()
fun isFooter(@IntRange(from = 0) position: Int): Boolean
获取数据
val headerCount: Int
val footerCount: Int
切换模式
切换模式相当于会提供一个回调函数遍历所有的item, 你可以在这个回调函数里面依次刷新他们.
常用于切换选择模式.
fun toggle()
// 切换模式
fun getToggleMode(): Boolean
// 范围当前出何种切换模式
fun setToggleMode(toggleMode: Boolean)
// 设置切换模式, 如果设置的是当前正处于的模式不会触发回调
回调函数
onToggle { type, position, toggleMode -> // 类型 位置 切换布尔值
// 在这里可以给item刷新成选择模式
}
// 切换完成
onToggleEnd {
// 例如切换工具栏为选择模式
}
选择模式
fun allChecked()
// 全选
fun allChecked(isAllChecked: Boolean)
// 全选或者全部取消全选
fun clearChecked()
// 取消全选
fun reverseChecked()
// 反选
fun setChecked(@IntRange(from = 0) position: Int, checked: Boolean)
// 设置某个item的选择状态
fun toggleChecked(@IntRange(from = 0) position: Int)
// 切换某个item的选择状态
fun <M> getCheckedModels(): List<M>
fun setCheckableType(@LayoutRes vararg checkableItemType: Int)
// 设置哪些type允许进入选择状态
val checkedCount: Int
拖拽/侧滑
只支持拖拽移动和侧滑删除
步骤:
- 开启
ItemTouchHelper
支持 - 数据模型继承
ItemModel
- 自定义扩展
BindingAdapter提供一个字段来开启ItemTouchHelper支持
var touchEnable = false // 默认关闭
然后数据模型要求继承ItemModel
, 根据需求重写函数.
示例:
data class Model(val name: String) : ItemModel() {
override fun getDrag(): Int {
return UP or DOWN
}
override fun getSwipe(): Int {
return RIGHT or LEFT
}
}
RIGHT or LEFT
是控制拖拽和侧滑的方向(侧滑不支持UP/DOWN)的常量.
拖拽移动item会自动改变数据模型在数据集合中的位置.
扩展功能
如果想要扩展ItemTouchHelper可以给BindingAdapter的变量itemTouchHelper
赋值
rv.linear().setup {
addType<Model>(R.layout.item)
touchEnable = true
itemTouchHelper = ItemTouchHelper(object : DefaultItemTouchCallback(this) {
// 这里可以重写函数
})
}.models = data
通过给view打上tag标签 swipe
可以控制侧滑将会移动的视图.
<RelativeLayout
android:layout_width="wrap_content"
android:layout_height="80dp"
android:orientation="horizontal"
android:tag="swipe"/>
缺省页
内部依赖 StateLayout, 该库支持任意 Activity | Fragment | View 实现缺省页功能.
主要特点
- 全局配置
- 单例配置
- 生命周期(可以加载动画或者处理事件)
- 支持activity/fragment/view替换
- 支持代码或者XML实现
- 无网络情况下showLoading显示错误布局, 有网则显示加载中布局
本库已经依赖, 无需再次依赖. 使用方法见GitHub.
PageRefreshLayout
该布局扩展自 SmartRefreshLayout(该库强烈推荐使用), 支持其所有特性. 本框架拥有最完美的缺省页功能
本库已引入SmartRefreshLayout 'com.scwang.smart:refresh-layout-kernel:2.0.0-alpha-1'
, 无需再次引入.
针对需要的请求头可以去其开源地址分包引入.
可选配置刷新头布局和脚布局
implementation 'com.scwang.smart:refresh-footer-classics:2.0.0-alpha-1' //经典加载
implementation 'com.scwang.smart:refresh-header-material:2.0.0-alpha-1' //谷歌刷新头
// 以上两种已内置
implementation 'com.scwang.smart:refresh-header-classics:2.0.0-alpha-1' //经典刷新头
implementation 'com.scwang.smart:refresh-header-radar:2.0.0-alpha-1' //雷达刷新头
implementation 'com.scwang.smart:refresh-header-falsify:2.0.0-alpha-1' //虚拟刷新头
implementation 'com.scwang.smart:refresh-header-two-level:2.0.0-alpha-1' //二级刷新头
implementation 'com.scwang.smart:refresh-footer-ball:2.0.0-alpha-1' //球脉冲加载
implementation 'com.scwang.smartrefresh:SmartRefreshHorizontal:1.0.0-andx-1' // 水平
刷新布局要求必须先初始化, 推荐在Application中
SmartRefreshLayout.setDefaultRefreshHeaderCreator { context, layout -> ClassicsHeader(this) }
SmartRefreshLayout.setDefaultRefreshFooterCreator { context, layout -> ClassicsFooter(this) }
在此基础上增加特性
- 缺省页
- 自动分页加载
- 支持KT特性
- 代码替换
创建方式
// 1. 代码创建, 通过扩展函数
val page = rv.page()
// 2. 布局包裹
<com.drake.brv.PageRefreshLayout xmlns:android="http://schemas.android.com/apk/res/android"
xmlns:tools="http://schemas.android.com/tools"
android:layout_width="match_parent"
xmlns:app="http://schemas.android.com/apk/res-auto"
android:id="@+id/page"
app:stateEnabled="true"
android:layout_height="match_parent"
tools:context="com.drake.brv.sample.fragment.RefreshFragment">
<androidx.recyclerview.widget.RecyclerView
android:id="@+id/rv"
android:layout_width="match_parent"
android:layout_height="match_parent" />
</com.drake.brv.PageRefreshLayout>
监听状态
// 下拉刷新
page.onRefresh {
// 这里可以进行网络请求等异步操作
}
// 上拉加载
page.onLoadMore {
// 这里可以进行网络请求等异步操作
}
如果onLoadMore
不调用则上拉加载同样也会回调onRefresh
函数, 因为下拉刷新和上拉加载可能都是走的同一个网络请求.
缺省页
触发刷新状态(两者都会回调函数onRefresh)
autoRefesh
这是触发的下拉刷新showLoading
这是触发的加载缺省页, 当然得先设置loadingLayout(或者读取全局缺省页配置)refresh
静默刷新, 不会触发任何动画
第2种方式一般用于初次进入页面时候加载数据(产品经理可能有这个要求), 这三种方式都会导致索引index=startIndex
重置.
缺省页状态控制
showEmpty()
showError()
showContent
showLoading()
配置全局缺省页
这块代码和StateLayout公用
/**
* 推荐在Application中进行全局配置缺省页, 当然同样每个页面可以单独指定缺省页.
* 具体查看 https://github.com/liangjingkanji/StateLayout
*/
StateConfig.apply {
emptyLayout = R.layout.layout_empty
errorLayout = R.layout.layout_error
loadingLayout = R.layout.layout_loading
onLoading {
// 此生命周期可以拿到LoadingLayout创建的视图对象, 可以进行动画设置或点击事件.
}
}
单例缺省页配置支持两种方式
- XML
<com.drake.brv.PageRefreshLayout
.....
app:error_layout="@layout/layout_error"
app:empty_layout="@layout/layout_empty"
app:loading_layout="@layout/layout_loading">
- 代码
page.apply {
loadingLayout = R.layout.layout_loading
emptyLayout = R.layout.layout_empty
errorLayout = R.layout.layout_error
}
默认会使用缺省页, 如果你已经设置了全局缺省页但是此刻不想使用. 可以使用属性|函数: stateEnabled
想要使用缺省页又要求缺省页不遮盖头布局, 头布局请使用CoordinatorLayout
实现. 注意使用NestedScrollView
会导致rv一次性加载完item内存消耗大.
刷新数据
前面提到 PageRefreshLayout 支持自动分页加载
// 设置分页加载第一页的索引, 默认=1, 触发刷新会重置索引. 如果需要修改在Application设置一次即可
// PageRefreshLayout.startIndex = 1
pageLayout.onRefresh {
// 下拉刷新和上拉加载都会执行这个网络请求, 除非另外设置onLoadMore
get("/path") {
param("key", "value")
param("page", pageLayout.index) // 这里使用框架提供的属性
}.page(this) {
// 该回调函数参数返回一个布尔类型用于判断是否存在下一页, 决定上拉加载的状态. 以及当前属于刷新还是加载更多条目
addData(data){ adapter.itemCount < data.count // 这里是判断是否由更多页, 具体逻辑根据接口定义 }
}
}
这里的网络请求使用的是我开源的另一个项目Net, 支持扩展BRV. GitHub: Net.
扩展
LayoutManager
框架还提供快速创建布局管理器的扩展函数, 上面使用示例
rv.linear().setup {
}
函数
fun RecyclerView.linear(
@RecyclerView.Orientation orientation: Int = VERTICAL,
reverseLayout: Boolean = false
)
fun RecyclerView.grid(
spanCount: Int,
@RecyclerView.Orientation orientation: Int = VERTICAL,
reverseLayout: Boolean = false
)
fun RecyclerView.staggered(
spanCount: Int,
@RecyclerView.Orientation orientation: Int = VERTICAL
)
分隔物
框架提供快速设置分隔物扩展函数
fun RecyclerView.divider(
@DrawableRes drawable: Int, // 分隔物Drawable
@RecyclerView.Orientation orientation: Int = RecyclerView.VERTICAL, // LayoutManager的方向
block: ((Rect, View, RecyclerView, RecyclerView.State) -> Boolean)? = null // getItemOffset回调用于设置间隔
)
示例
rv.linear().divider(R.drawable.divider_horizontal_padding_15dp).setup {
}
对话框
通过扩展函数快速给对话框创建列表
Dialog(context).setAdapter(bindingAdapter)
