dubbo+zipkin调用链监控

470 阅读5分钟

图片描述(最多50字) 收集器抽象

由于zipkin支持http以及kafka两种方式上报数据,所以在配置上需要做下抽象。

AbstractZipkinCollectorConfiguration

主要是针对下面两种收集方式的一些配置上的定义,最核心的是Sender接口的定义,http与kafka是两类完全不同的实现。

public abstract Sender getSender(); 其次是协助性的构造函数,主要是配合构建收集器所需要的一些参数。

zipkinUrl 如果是http收集,那么对应的是zipkin api域名,如果是kafka,对应的是kafka集群的地址

topic 仅在收集方式为kafka是有效,http时传空值即可。

public AbstractZipkinCollectorConfiguration(String serviceName,String zipkinUrl,String topic){ this.zipkinUrl=zipkinUrl; this.serviceName=serviceName; this.topic=topic; this.tracing=this.tracing(); } 配置上报方式,这里统一采用异常上传,并且配置上报的超时时间。

protected AsyncReporter spanReporter() { return AsyncReporter .builder(getSender()) .closeTimeout(500, TimeUnit.MILLISECONDS) .build(SpanBytesEncoder.JSON_V2); } 下面这两方法,是配合应用构建span使用的。

注意那个sampler()方法,默认是什么也不做的意思,我们要想看到数据就需要配置成Sampler.ALWAYS_SAMPLE,这样才能真正将数据上报到zipkin服务器。 protected Tracing tracing() { this.tracing= Tracing .newBuilder() .localServiceName(this.serviceName) .sampler(Sampler.ALWAYS_SAMPLE) .spanReporter(spanReporter()) .build(); return this.tracing; } protected Tracing getTracing(){ return this.tracing; } HttpZipkinCollectorConfiguration

主要是实现getSender方法,可以借用OkHttpSender这个对象来快速构建,api版本采用v2。

public class HttpZipkinCollectorConfiguration extends AbstractZipkinCollectorConfiguration { public HttpZipkinCollectorConfiguration(String serviceName,String zipkinUrl) { super(serviceName,zipkinUrl,null); } @Override public Sender getSender() { return OkHttpSender.create(super.getZipkinUrl()+"/api/v2/spans"); } } OkHttpSender这个类需要引用这个包

io.zipkin.reporter2 zipkin-sender-okhttp3 ${zipkin-reporter2.version} KafkaZipkinCollectorConfiguration

同样也是实现getSender方法

public class KafkaZipkinCollectorConfiguration extends AbstractZipkinCollectorConfiguration { public KafkaZipkinCollectorConfiguration(String serviceName,String zipkinUrl,String topic) { super(serviceName,zipkinUrl,topic); } @Override public Sender getSender() { return KafkaSender .newBuilder() .bootstrapServers(super.getZipkinUrl()) .topic(super.getTopic()) .encoding(Encoding.JSON) .build(); } } KafkaSender这个类需要引用这个包:

io.zipkin.reporter2 zipkin-sender-kafka11 ${zipkin-reporter2.version} 收集器工厂

由于上面创建了两个收集器配置类,使用时只能是其中之一,所以实际运行的实例需要根据配置来动态生成。ZipkinCollectorConfigurationFactory就是负责生成收集器实例的。

private final AbstractZipkinCollectorConfiguration zipkinCollectorConfiguration; @Autowired public ZipkinCollectorConfigurationFactory(TraceConfig traceConfig){ if(Objects.equal("kafka", traceConfig.getZipkinSendType())){ zipkinCollectorConfiguration=new KafkaZipkinCollectorConfiguration( traceConfig.getApplicationName(), traceConfig.getZipkinUrl(), traceConfig.getZipkinKafkaTopic()); } else { zipkinCollectorConfiguration = new HttpZipkinCollectorConfiguration( traceConfig.getApplicationName(), traceConfig.getZipkinUrl()); } } 通过构建函数将我们的配置类TraceConfig注入进来,然后根据发送方式来构建实例。另外提供一个辅助函数:

public Tracing getTracing(){ return this.zipkinCollectorConfiguration.getTracing(); } 过滤器

在dubbo的过滤器中实现数据上传的功能逻辑相对简单,一般都在invoke方法执行前记录数据,然后方法执行完成后再次记录数据。这个逻辑不变,有变化的是数据上报的实现,上一个版本是通过发http请求实现需要编码,现在可以直接借用brave所提供的span来帮助我们完成,有两重要的方法:

finish 方法源码如下,在完成的时候会填写上完成的时间并上报数据,这一般应用于同步调用场景。

public void finish(TraceContext context, long finishTimestamp) { MutableSpan span = this.spanMap.remove(context); if(span != null && !this.noop.get()) { synchronized(span) { span.finish(Long.valueOf(finishTimestamp)); this.reporter.report(span.toSpan()); } } } flush 与上面finish方法的不同点在于,在报数据时没有完成时间,这应该是适用于一些异步调用但不关心结果的场景,比如dubbo所提供的oneway方式调用。 public void flush(TraceContext context) { MutableSpan span = this.spanMap.remove(context); if(span != null && !this.noop.get()) { synchronized(span) { span.finish((Long)null); this.reporter.report(span.toSpan()); } } } 消费者

做为消费方,有一个核心功能就是将traceId以及spanId传递到服务提供方,这里还是通过dubbo提供的附加参数方式实现。

@Override public Result invoke(Invoker<?> invoker, Invocation invocation) throws RpcException { if(!RpcTraceContext.getTraceConfig().isEnabled()){ return invoker.invoke(invocation); } ZipkinCollectorConfigurationFactory zipkinCollectorConfigurationFactory= SpringContextUtils.getApplicationContext().getBean(ZipkinCollectorConfigurationFactory.class); Tracer tracer= zipkinCollectorConfigurationFactory.getTracing().tracer(); if(null==RpcTraceContext.getTraceId()){ RpcTraceContext.start(); RpcTraceContext.setTraceId(IdUtils.get()); RpcTraceContext.setParentId(null); RpcTraceContext.setSpanId(IdUtils.get()); } else { RpcTraceContext.setParentId(RpcTraceContext.getSpanId()); RpcTraceContext.setSpanId(IdUtils.get()); } TraceContext traceContext= TraceContext.newBuilder() .traceId(RpcTraceContext.getTraceId()) .parentId(RpcTraceContext.getParentId()) .spanId(RpcTraceContext.getSpanId()) .sampled(true) .build(); Span span=tracer.toSpan(traceContext).start(); invocation.getAttachments().put(RpcTraceContext.TRACE_ID_KEY, String.valueOf(span.context().traceId())); invocation.getAttachments().put(RpcTraceContext.SPAN_ID_KEY, String.valueOf(span.context().spanId())); Result result = invoker.invoke(invocation); span.finish(); return result; } 提供者

@Override public Result invoke(Invoker<?> invoker, Invocation invocation) throws RpcException { if(!RpcTraceContext.getTraceConfig().isEnabled()){ return invoker.invoke(invocation); } Map<String, String> attaches = invocation.getAttachments(); if (!attaches.containsKey(RpcTraceContext.TRACE_ID_KEY)){ return invoker.invoke(invocation); } Long traceId = Long.valueOf(attaches.get(RpcTraceContext.TRACE_ID_KEY)); Long spanId = Long.valueOf(attaches.get(RpcTraceContext.SPAN_ID_KEY)); attaches.remove(RpcTraceContext.TRACE_ID_KEY); attaches.remove(RpcTraceContext.SPAN_ID_KEY); RpcTraceContext.start(); RpcTraceContext.setTraceId(traceId); RpcTraceContext.setParentId(spanId); RpcTraceContext.setSpanId(IdUtils.get()); ZipkinCollectorConfigurationFactory zipkinCollectorConfigurationFactory= SpringContextUtils.getApplicationContext().getBean(ZipkinCollectorConfigurationFactory.class); Tracer tracer= zipkinCollectorConfigurationFactory.getTracing().tracer(); TraceContext traceContext= TraceContext.newBuilder() .traceId(RpcTraceContext.getTraceId()) .parentId(RpcTraceContext.getParentId()) .spanId(RpcTraceContext.getSpanId()) .sampled(true) .build(); Span span = tracer.toSpan(traceContext).start(); Result result = invoker.invoke(invocation); span.finish(); return result; } 异常流程

上面无论是消费者的过滤器还是服务提供者的过滤器,均未考虑服务在调用invoker.invoke时出错的场景,如果出错,后面的span.finish方法将不会按预期执行,也就记录不了信息。所以需要针对此问题做优化:可以在finally块中执行finish方法。

try { result = invoker.invoke(invocation); } finally { span.finish(); } 消费者在调用服务时,异步调用问题

上面过滤器中调用span.finish都是基于同步模式,而由于dubbo除了同步调用外还提供了两种调用方式

异步调用 通过callback机制的异步 oneway 只发起请求并不等待结果的异步调用,无callback一说

针对上面两类异步再加上同步调用,我们要想准确记录服务真正的时间,需要在消费方的过滤器中做如下处理: 创建一个用于回调的处理类,它的主要目的是为了在回调成功时记录时间,这里无论是成功还是失败。

private class AsyncSpanCallback implements ResponseCallback{ private Span span; public AsyncSpanCallback(Span span){ this.span=span; } @Override public void done(Object o) { span.finish(); } @Override public void caught(Throwable throwable) { span.finish(); } } 再在调用invoke方法时,如果是oneway方式,则调用flush方法结果,如果是同步则直接调用finish方法,如果是异步则在回调时调用finish方法。

Result result = null; boolean isOneway = RpcUtils.isOneway(invoker.getUrl(), invocation); try { result = invoker.invoke(invocation); } finally { if(isOneway) { span.flush(); } else if(!isAsync) { span.finish(); } }
